MSP430FR2153TPTR - Texas Instruments

Manufacturer Part Number

MSP430FR2153TPTR

Manufacturer

Texas Instruments

Introduction

The MSP430FR2153TPTR microcontroller, part of the MSP430™ FRAM series by Texas Instruments, is a 16-bit device designed for embedded applications requiring low power consumption and high performance.

Product Features and Performance

Core Processor: MSP430 CPU16

Core Size: 16-Bit

Speed: 24MHz

Connectivity: I2C, IrDA, SPI, UART/USART

Peripherals: Brown-out Detect/Reset, Power-On Reset (POR), Pulse Width Modulation (PWM), Watchdog Timer (WDT)

Number of I/O: 44

Program Memory Size: 16KB (16K x 8)

Program Memory Type: FRAM

RAM Size: 2K x 8

Data Converters: 12-bit ADC with 12 channels

Oscillator Type: Internal

Operating Temperature Range: -40°C to 105°C

Product Advantages

Integration of multiple communication interfaces

Ultra-low-power consumption

Robust peripheral set enhancing functionality

Extended operating temperature suitable for industrial applications

FRAM technology enabling faster writes, extended endurance, and lower power

Key Technical Parameters

Program Memory: 16KB FRAM

RAM: 2KB

Voltage Supply: 1.8V to 3.6V

12-bit ADC with 12 channels

Temperature Range: -40°C to 105°C

Quality and Safety Features

Brown-out Detect/Reset for system reliability

Power-On Reset (POR) to ensure correct power-up sequencing

Compatibility

Surface mount 48-LQFP (7x7) package compatible with common PCB designs

Application Areas

Industrial control systems

Wireless sensors

Energy harvesting applications

Consumer Electronics

Product Lifecycle

Status: Active

Ready availability with no current plans for discontinuation

Several Key Reasons to Choose This Product

Highly integrated device with powerful 16-bit CPU

Versatile connectivity options including I2C, SPI, and UART/USART

FRAM for superior performance in write operations and low power usage

Diverse range of peripherals supporting complex applications

Long operating temperature range suitable for harsh environments

Reliable quality and extended product life with TI’s support and technology advancements
