WL1837MODGIMOCR - Texas Instruments

Manufacturer Part Number

WL1837MODGIMOCR

Manufacturer

Texas Instruments

Introduction

Highly integrated 2.4GHz and 5GHz dual-band Wi-Fi and Bluetooth combo module

Product Features and Performance

Supports 802.11a/b/g/n Wi-Fi and Bluetooth v4.2

Dual-band operation at 2.4GHz and 5GHz

Output power up to 18dBm

Receive sensitivity down to -95dBm

Transmit current from 243mA to 510mA

Receive current from 49mA to 85mA

Serial interfaces include SDIO and UART

Product Advantages

Highly integrated design reduces BOM and board space

Provides both Wi-Fi and Bluetooth connectivity

Supports wide operating temperature range of -40°C to 85°C

Tape and reel packaging for efficient manufacturing

Key Technical Parameters

Frequency: 2.4GHz, 5GHz

Operating Temperature: -40°C to 85°C

Supply Voltage: 2.9V to 4.8V

Mounting Type: Surface Mount

Transmit Current: 243mA to 510mA

Receive Current: 49mA to 85mA

Output Power: 18dBm

Sensitivity: -95dBm

Data Rate: Up to 54Mbps

Modulation: CCK, DSSS, GFSK, OFDM

Quality and Safety Features

Tape and reel packaging for reliable manufacturing

Supports wide operating temperature range

Compatibility

Designed to be compatible with various wireless applications and systems

Application Areas

Suitable for a wide range of wireless applications, such as:

- IoT devices

- Wearables

- Smart home systems

- Industrial automation

- Automotive infotainment

Product Lifecycle

This product is an active and current offering from Texas Instruments.

Replacements and upgrades may be available in the future as technology evolves.

Key Reasons to Choose This Product

Highly integrated design for reduced BOM and board space

Dual-band Wi-Fi and Bluetooth connectivity in a single module

Excellent performance with high output power and sensitivity

Wide operating temperature range suitable for various environments

Efficient tape and reel packaging for reliable manufacturing
