WL1831MODGBMOCR - Texas Instruments

Manufacturer Part Number

WL1831MODGBMOCR

Manufacturer

Texas Instruments

Introduction

Integrated RF transceiver module for Bluetooth and Wi-Fi applications

Combines Bluetooth and Wi-Fi functionality in a single chip

Product Features and Performance

Supports Bluetooth 4.2 and Wi-Fi 802.11b/g/n

Frequency range: 2.4GHz

Transmit power: 17.3dBm

Receive sensitivity: -96.3dBm

Data rates up to 54Mbps

Modulation schemes: CCK, DSSS, GFSK, OFDM

Supply voltage: 2.9V to 4.8V

Operating temperature: -20°C to 70°C

Low power consumption: 238mA (TX), 49mA (RX)

Product Advantages

Integrated Bluetooth and Wi-Fi functionality in a single module

Compact 100-SMD package

Supports a wide range of operating voltages and temperatures

Robust RF performance with high transmit power and sensitivity

Key Technical Parameters

Frequency: 2.4GHz

Data rate: Up to 54Mbps

Modulation: CCK, DSSS, GFSK, OFDM

Supply voltage: 2.9V to 4.8V

Operating temperature: -20°C to 70°C

Transmit current: 238mA to 420mA

Receive current: 49mA to 85mA

Quality and Safety Features

RoHS3 compliant

Tape and reel packaging for surface mount assembly

Compatibility

Compatible with Bluetooth 4.2 and Wi-Fi 802.11b/g/n devices

Application Areas

Wireless connectivity in consumer electronics, IoT devices, and industrial applications

Product Lifecycle

Currently in active production

Replacement or upgrade options available from Texas Instruments

Key Reasons to Choose This Product

Integrated Bluetooth and Wi-Fi functionality in a single module

Robust RF performance with high transmit power and sensitivity

Wide operating voltage and temperature range

Compact and easy-to-integrate 100-SMD package

RoHS3 compliance for environmental considerations

Availability of replacement and upgrade options from the manufacturer
