HomeProductsIntegrated Circuits (ICs)PMIC - Power Distribution Switches, Load DriversTPS2001CDGNR
TPS2001CDGNR Image
TPS2001CDGNR Image - 1
Image may be representation.
See specifications for product details.
Share
 Favorite

TPS2001CDGNR - Texas Instruments

Manufacturer Part Number
TPS2001CDGNR
Manufacturer
Texas Instruments
Allelco Part Number
32D-TPS2001CDGNR
ECAD Model
Parts Description
IC PWR SWITCH N-CHAN 1:1 8MSOP
Detailed Description
Package
8-TSSOP, 8-MSOP (0.118', 3.00mm Width) Exposed Pad
Data sheet
TPS20xxC.pdf
RoHs Status
ROHS3 Compliant
Compare
In stock: 104780

Required fields are indicated by an asterisk (*)
Please send RFQ, we will respond immediately.

Quantity

Specifications

TPS2001CDGNR Tech Specifications
Texas Instruments - TPS2001CDGNR technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - TPS2001CDGNR

Product Attribute Attribute Value
Manufacturer Texas Instruments
Voltage - Supply (Vcc/Vdd) Not Required
Voltage - Load 4.5V ~ 5.5V
Switch Type USB Switch
Supplier Device Package 8-HVSSOP
Series -
Rds On (Typ) 72mOhm
Ratio - Input:Output 1:1
Package / Case 8-TSSOP, 8-MSOP (0.118', 3.00mm Width) Exposed Pad
Package Tape & Reel (TR)
Output Type N-Channel
Product Attribute Attribute Value
Output Configuration High Side
Operating Temperature -40°C ~ 125°C (TJ)
Number of Outputs 1
Mounting Type Surface Mount
Interface On/Off
Input Type Non-Inverting
Features Status Flag
Fault Protection Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO
Current - Output (Max) 2A
Base Product Number TPS2001

Parts Introduction

Manufacturer Part Number

TPS2001CDGNR

Manufacturer

Texas Instruments

Introduction

Integrated Circuit (IC) for power distribution and load driving

Product Features and Performance

N-Channel MOSFET switch

Single output

High-side switch configuration

5V to 5.5V operating voltage range

2A maximum output current

72mΩ typical on-resistance

Fault protection: current limiting, over-temperature, reverse current, UVLO

Product Advantages

Integrated power switch for simplified design

Fault protection features improve system reliability

Small 8-HVSSOP package for space-constrained applications

Key Technical Parameters

Operating temperature range: -40°C to 125°C

RoHS3 compliant

Quality and Safety Features

Fault protection mechanisms

Robust thermal management

Compatibility

Compatible with a wide range of low-voltage systems and devices

Application Areas

Power distribution and load driving in USB, mobile, and portable electronics

Product Lifecycle

Current product offering, no discontinuation or replacement plans identified

Key Reasons to Choose This Product

Integrated power switch with fault protection for reliable performance

Small package size for space-constrained designs

Wide operating temperature range suitable for various environmental conditions

RoHS3 compliance for environmentally-friendly applications

Parts with Similar Specifications

The three parts on the right have similar specifications to Texas Instruments TPS2001CDGNR

Product Attribute TPS2001CDGNR TPS2000CDGKR TPS2001CDGK TPS1HB50BQPWPRQ1
Part Number TPS2001CDGNR TPS2000CDGKR TPS2001CDGK TPS1HB50BQPWPRQ1
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Operating Temperature -40°C ~ 125°C (TJ) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 125°C (TA)
Input Type Non-Inverting Inverting Non-Inverting Non-Inverting
Base Product Number TPS2001 TPS2000 TPS2001 TPS1HB50
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount
Output Type N-Channel N-Channel N-Channel N-Channel
Supplier Device Package 8-HVSSOP 8-VSSOP 8-VSSOP 16-HTSSOP
Fault Protection Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO Current Limiting (Adjustable), Over Temperature
Features Status Flag - - Slew Rate Controlled
Voltage - Load 4.5V ~ 5.5V 4.5V ~ 5.5V 4.5V ~ 5.5V 6V ~ 18V
Output Configuration High Side High Side High Side High Side
Rds On (Typ) 72mOhm 72mOhm 72mOhm 50mOhm
Switch Type USB Switch USB Switch USB Switch General Purpose
Number of Outputs 1 1 1 1
Current - Output (Max) 2A 2A 2A 18A
Ratio - Input:Output 1:1 1:1 1:1 1:1
Voltage - Supply (Vcc/Vdd) Not Required Not Required Not Required Not Required
Series - - - Automotive, AEC-Q100
Package Tape & Reel (TR) Tape & Reel (TR) Tube Tape & Reel (TR)
Interface On/Off On/Off On/Off On/Off
Package / Case 8-TSSOP, 8-MSOP (0.118', 3.00mm Width) Exposed Pad 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) 16-PowerTSSOP (0.173", 4.40mm Width)

TPS2001CDGNR Datasheet PDF

Download TPS2001CDGNR pdf datasheets and Texas Instruments documentation for TPS2001CDGNR - Texas Instruments.

HTML Datasheet
TPS20xxC.pdf
PCN Assembly/Origin
2.73KHz.pdf
