Manufacturer Part Number
SN74LVC2G04DBVT
Manufacturer
Texas Instruments
Introduction
Dual Inverter Gate IC
Product Features and Performance
2 independent inverters
High-speed CMOS logic
Low power consumption
Wide supply voltage range (1.65V to 5.5V)
Low input/output capacitance
High noise immunity
Fast propagation delay (3.2ns max)
Product Advantages
Compact and space-saving SOT-23-6 package
Wide operating temperature range (-40°C to 125°C)
RoHS-3 compliant
Key Technical Parameters
2 Inputs, 2 Outputs
Quiescent current: 10μA (max)
Output current (high/low): 32mA
Input logic levels: 0.7V to 0.8V (low), 1.7V to 2V (high)
Quality and Safety Features
RoHS-3 compliant
Electrostatic discharge (ESD) protection
Compatibility
Compatible with 3.3V and 5V logic systems
Application Areas
General-purpose logic functions
Signal inversion
Digital circuits
Product Lifecycle
Active product
Replacements and upgrades available
Key Reasons to Choose
Compact and space-saving package
Wide supply voltage and temperature range
High-speed and low-power operation
RoHS compliance for environmental responsibility
Availability of replacements and upgrades
