SN74LVC2G02DCTR - Texas Instruments

Manufacturer Part Number

SN74LVC2G02DCTR

Manufacturer

Texas Instruments

Introduction

Texas Instruments' SN74LVC2G02DCTR is a dual 2-input positive-NOR gate from the 74LVC family designed for use in a wide range of digital applications.

Product Features and Performance

Dual 2-input NOR logic gate

Low power consumption

Broad voltage range compatibility

High-speed operation

Low input capacitance

Product Advantages

Supports 5V tolerant inputs

Ensures low static and dynamic power consumption

Enhanced signal integrity with balanced propagation delays

Operates from a wide voltage range for flexibility

Key Technical Parameters

Logic Type: NOR Gate

Number of Circuits: 2

Number of Inputs: 2

Voltage - Supply: 1.65V to 5.5V

Current - Quiescent (Max): 10 µA

Current - Output High, Low: 32mA, 32mA

Input Logic Level - Low: 0.7V to 0.8V

Input Logic Level - High: 1.7V to 2V

Max Propagation Delay @ V, Max CL: 4.4ns @ 5V, 50pF

Quality and Safety Features

Extended temperature range operation

Lead-free and RoHS compliant

Robust ESD protection

Compatibility

Compatible with down-voltage applications

Interfacing with 5V logic levels possible

Application Areas

Computing systems

Networking equipment

Portable electronics

Consumer electronics

Data storage devices

Industrial automation

Product Lifecycle

Product Status: Active

Not currently nearing discontinuation

Manufacturer support for replacements or upgrades available

Several Key Reasons to Choose This Product

Efficient power usage allows for inclusion in power-sensitive applications

Fast signal processing capabilities for high-speed systems

Broad compatibility with multiple logic families simplifies design integration

Compact surface-mount packaging saves board space

Long-term operational reliability in extreme temperature conditions

Industry-standard product with strong manufacturer support
