PGA204BU - Texas Instruments

Manufacturer Part Number

PGA204BU

Manufacturer

Texas Instruments

Introduction

High-Precision Instrumentation Amplifier

Product Features and Performance

Low Input Offset Voltage of 10 μV

Low Input Bias Current of 500 pA

High Gain Bandwidth of 1 MHz

Wide Supply Voltage Range from 9V to 36V

Low Quiescent Current of 5.2 mA

Slew Rate of 0.7 V/μs

Product Advantages

Excellent Precision and Stability

Wide Dynamic Range

Low Power Consumption

Fast Settling Time

Key Technical Parameters

Supply Voltage Range: 9V to 36V

Input Offset Voltage: 10 μV

Input Bias Current: 500 pA

Gain Bandwidth: 1 MHz

Quiescent Current: 5.2 mA

Slew Rate: 0.7 V/μs

Operating Temperature: -40°C to 85°C

Quality and Safety Features

RoHS3 Compliant

Surface Mount 16-SOIC Package

Compatibility

Suitable for a Wide Range of Instrumentation and Measurement Applications

Application Areas

Industrial Automation

Medical Instrumentation

Test and Measurement Equipment

Process Control Systems

Product Lifecycle

Currently in Production

Replacement or Upgrade Options Available from Texas Instruments

Key Reasons to Choose This Product

Excellent Precision and Stability for Sensitive Measurements

Wide Operating Voltage Range for Flexibility

Low Power Consumption for Energy-Efficient Designs

Fast Response Time for Dynamic Applications

Proven Reliability and Quality from Texas Instruments
