Manufacturer Part Number
MSP430F169IPMR
Manufacturer
Texas Instruments
Introduction
Microcontroller unit from Texas Instruments' MSP430 family designed for low-power embedded applications
Product Features and Performance
16-Bit MSP430 CPU16 core processor
Operating speed of 8 MHz
Comprehensive connectivity options including I2C, SPI, and UART/USART
Equipped with peripherals like Brown-out Detect/Reset, DMA, POR, PWM, and WDT
Features 48 I/O pins
Embedded 60KB FLASH memory for program storage plus 256B
RAM of 2K x 8 for data processing
Integrated A/D and D/A converters with multiple channels (8x12b A/D, 2x12b D/A)
Internal oscillator for clock generation
Designed for surface mounting with 64-LQFP package
Product Advantages
High Integration allows for reduced system complexity
Low power consumption suitable for battery-powered applications
Advanced control peripherals facilitate complex functions
The extensive development ecosystem of Texas Instruments' MSP430
Key Technical Parameters
Core Size 16-Bit
Speed 8MHz
Program Memory Size 60KB FLASH
RAM Size 2K x 8
Voltage - Supply 1.8V to 3.6V
Operating Temperature range from -40°C to 85°C
Quality and Safety Features
Brown-out Detect for reliable operation under variable power conditions
Watchdog Timer (WDT) ensures system recovery
Build according to industry quality and safety standards
Compatibility
Based on a widely supported MSP430 platform
Compatibility with various MSP430 development tools and software
Application Areas
Automotive systems
Portable and battery-powered devices
Industrial controls
Consumer Electronics
Wireless and IoT applications
Product Lifecycle
The product status is Active
Products from the MSP430x1xx series have a long life cycle and good support from Texas Instruments
Several Key Reasons to Choose This Product
Low power consumption enables extended battery life
Feature-rich peripherals support diversified application requirements
Broad operating voltage range enhances adaptability in different power environments
Comprehensive development tools simplify the design and development process
Large number of I/O provides great flexibility in interfacing with external components
A strong community and support ecosystem help in troubleshooting and knowledge building
