STDRIVE601TR - STMicroelectronics

Manufacturer Part Number

STDRIVE601TR

Manufacturer

STMicroelectronics

Introduction

STDRIVE601TR is an integrated power management IC designed for full-half-bridge motor drivers.

Product Features and Performance

Advanced Power MOSFET Technology

Capable of Driving Capacitive and Resistive Loads

Integrated Bootstrap Circuit

High Voltage Load Capabilities up to 580V

Supports Analog and Logic Interface

Designed for DC Motor Control and General Purpose Applications

Product Advantages

High-Voltage Handling

Enhanced Thermal Performance

Integrated Fault Protection Features

High Reliability and Robust Design

Low Rds On for Increased Efficiency

Key Technical Parameters

Output Configuration: Half Bridge (3)

Rds On (Typ): 35Ohm

Current - Peak Output: 350mA

Voltage - Supply Range: 9V to 20V

Operating Temperature Range: -40°C to 125°C

Quality and Safety Features

Over Current Protection

Over Temperature Protection

Under Voltage Lock Out (UVLO)

Rigorous Testing for Quality Assurance

Compatibility

Motor Driver Applications Requiring High Voltage

Capacitive and Resistive Load Applications

Application Areas

Automotive Industry

Industrial Motor Control

Consumer Electronics

Home Appliances

Automation Systems

Product Lifecycle

Active Product Status

Availability of Replacements and Upgrades

Several Key Reasons to Choose This Product

Optimized for High-Voltage Applications up to 580V

Diverse Application Suitability from Automotive to Industrial

Robust Design with Built-In Fault Protection Mechanisms

Energy-Efficient Operation with Low Rds On Values

Reliable Performance over a Wide Temperature Range
