TS5USBC400YFPR - Texas Instruments

Manufacturer Part Number

TS5USBC400YFPR

Manufacturer

Texas Instruments

Introduction

TS5USBC400YFPR is a specialized interface analog switch designed for USB and UART applications.

Product Features and Performance

Bi-Directional functionality

Multiplexer/Demultiplexer Circuit: 2:1, 1:2

On-State Resistance (Max): 9 Ohm

Voltage Supply, Single (V+): 2.3V to 5.5V

-3db Bandwidth: 1.1GHz

Operating Temperature Range: 0°C ~ 70°C

Mounting Type: Surface Mount

12-XFBGA, DSBGA packaging for compact design

Product Advantages

Efficient switching between USB and UART applications

Low on-state resistance helps minimizing power loss

Wide voltage supply range enables flexibility in application designs

High bandwidth suitable for fast data transfer rates

Key Technical Parameters

Number of Channels: 2

On-State Resistance: 9 Ohm Max

Voltage Supply: 2.3V ~ 5.5V

-3db Bandwidth: 1.1GHz

Operating Temperature: 0°C ~ 70°C

Quality and Safety Features

Robust surface mount packaging (12-DSBGA)

Operates reliably within a wide temperature range

Compatibility

Compatible with devices requiring USB/UART interface switching within the specified voltage and bandwidth parameters.

Application Areas

Consumer Electronics

Communication Equipment

Computing Peripheral Devices

Product Lifecycle

Currently active with no indication of nearing discontinuation. Future upgrades or replacements haven't been specified.

Several Key Reasons to Choose This Product

High-performance bi-directional switch for efficient interface management

Low resistance and wide voltage supply range supports diverse applications

High bandwidth capability facilitating fast data transfer

Robust packaging suitable for standard surface mount technology

Tailored for modern communication and consumer electronic devices
