TS5USBC400IYFPR - Texas Instruments

Manufacturer Part Number

TS5USBC400IYFPR

Manufacturer

Texas Instruments

Introduction

The TS5USBC400IYFPR is a specialized interface analog switch designed for USB and UART applications.

Product Features and Performance

Supports USB and UART signaling

Bi-directional interface switch

Multiplexer/Demultiplexer Circuit: 2:1, 1:2

Provides 2 channels

On-State Resistance (Max): 9Ohm

Voltage Supply Range: 2.3V to 5.5V

High -3dB Bandwidth: 1.1GHz

Operating Temperature: -40°C to 85°C

Product Advantages

Low on-state resistance enhances signal integrity

Wide voltage supply range increases compatibility

High bandwidth suitable for high-speed data applications

Robust operating temperature for various environmental conditions

Key Technical Parameters

Number of Channels: 2

On-State Resistance: 9Ohm

Voltage Supply, Single (V+): 2.3V to 5.5V

-3db Bandwidth: 1.1GHz

Operating Temperature: -40°C to 85°C

Quality and Safety Features

Designed to meet stringent industry standards

Reliable performance in a range of temperatures

Compatibility

Compatible with USB and UART interfaces

Suitable for a variety of digital communication protocols

Application Areas

Consumer Electronics

Communication Devices

Data Transfer Systems

Product Lifecycle

Product Status: Active

No immediate discontinuation expected

Upgrades or replacements are available for future needs

Several Key Reasons to Choose This Product

Exceptional signal integrity due to low on-state resistance

Versatile power supply requirements suitable for multiple designs

Capable of handling high-speed data transmissions

Durable and reliable across a wide range of operating temperatures

Strong compatibility with prevalent communication interfaces
