TPS2060CDGNR - Texas Instruments

Manufacturer Part Number

TPS2060CDGNR

Manufacturer

Texas Instruments

Introduction

Integrated power distribution switch for managing power in electronic systems

Product Features and Performance

Dual-channel power distribution switch

General Purpose switch type

High-side output configuration

N-Channel output type

On/Off interface switch control

Support for 4.5V to 5.5V load voltage

No external supply required for device operation

Up to 1.5A output current capacity

70mOhm typical Rds On

Non-Inverting input type

Features Load Discharge and Status Flag indicators

Fault Protection includes Current Limiting, Over Temperature, Reverse Current, and Under Voltage Lock Out (UVLO)

Product Advantages

Supports multiple fault protection features enhancing system reliability

Efficient power distribution with low Rds On

Compact 8-HVSSOP package saves space on PCB

Integrated status flag for system diagnostics

Key Technical Parameters

Number of Outputs: 2

Ratio - Input:Output: 1:2

Maximum Output Current: 1.5A

Voltage - Load: 4.5V to 5.5V

Rds On (Typical): 70mOhm

Operating Temperature Range: -40°C to 125°C

Quality and Safety Features

Built-in fault protection mechanisms

Operational across a wide temperature range for enhanced reliability

Status flag for real-time monitoring

Compatibility

Surface mount compatible in an 8-TSSOP, 8-MSOP package

Designed for use with 4.5V to 5.5V systems

Application Areas

Power management in computing devices

USB power distribution and management

Industrial controls

Battery-powered devices

Consumer electronics

Product Lifecycle

Active product status with Texas Instruments

No indication of discontinuation, ensures long-term availability

Several Key Reasons to Choose This Product

Texas Instruments' reputed manufacturing for high reliability

Robust power management with multiple integrated protections

Flexible for various power distribution applications

High efficiency with low Rds On

Real-time fault detection aids in system maintenance and monitoring

Designed to operate in harsh environments with wide temperature range

Simple on/off control interface for ease of use

Low-profile, space-saving package suitable for compact PCB designs
