SN74LVC1G32DSFR - Texas Instruments

Manufacturer Part Number

SN74LVC1G32DSFR

Manufacturer

Texas Instruments

Introduction

The SN74LVC1G32DSFR is a single 2-input positive OR gate from Texas Instruments' 74LVC series.

Product Features and Performance

Logic Type: OR Gate

Number of Circuits: 1

Number of Inputs: 2

Low Power Consumption

High-Speed Operation

Input Compatibility with Various Voltage Levels

Product Advantages

Supports 5 V Tolerant Inputs

Ensures Low Voltage Operation

Reduced Power Consumption with Maximum Quiescent Current of 10 µA

High Output Current of 32mA (High and Low)

Optimized for High-Speed Signal Processing

Key Technical Parameters

Voltage - Supply: 1.65V to 5.5V

Max Propagation Delay @ V, Max CL: 4ns at 5V, with 50pF Load

Input Logic Level - Low: 0.7V to 0.8V

Input Logic Level - High: 1.7V to 2V

Operating Temperature Range: -40°C to 125°C

Quality and Safety Features

Robust Operating Temperature Range Ensuring Reliability in Various Environments

Compatibility

Designed for Easy Mounting on Surfaces with 6-SON (1x1) Package

Compatible with TTL Levels

Application Areas

Ideal for High-Speed Logic Switching

Suitable for a Variety of Electronic Circuits

Widely Used in Consumer Electronics, Computing, and Industrial Applications

Product Lifecycle

Product Status: Active

No Indication of Near Discontinuation

Replacement and Upgrade Options are Typically Available

Several Key Reasons to Choose This Product

Broad Compatibility with 1.65V to 5.5V Supply Voltages

High-Speed Performance with Low Propagation Delays

Efficient Power Consumption Ideal for Battery-Powered Applications

Enhanced Reliability with a Wide Operating Temperature Range

Texas Instruments' Reputation for High-Quality and Durable Components

Supports Current Industry Standard Logic Level Specifications for Easy Integration

Availability of Technical Support and Documentation from Manufacturer
