LMG3411R050RWHT - Texas Instruments

Manufacturer Part Number

LMG3411R050RWHT

Manufacturer

Texas Instruments

Introduction

High-side P-channel power distribution switch with integrated bootstrap diode and regulator.

Product Features and Performance

Bootstrap circuit for driving the high-side P-channel MOSFET

5V regulated output

1:1 input-to-output ratio

Logic and PWM control interfaces

Fault protection: over-current, over-temperature, UVLO

Low RDS(ON) of 57mΩ

Maximum voltage of 480V and current of 12A

Product Advantages

Integrated bootstrap circuit and regulator simplifies design

High efficiency and low power consumption

Robust fault protection

Wide operating temperature range of -40°C to 125°C

Key Technical Parameters

Operating voltage: 9.5V to 18V

32-VQFN (8x8) package

Surface mount design

P-channel output configuration

1 output

Quality and Safety Features

RoHS3 compliant

Robust fault protection against over-current, over-temperature, and UVLO

Compatibility

Can be used in a variety of power distribution and load control applications.

Application Areas

Industrial automation

Automotive electronics

Power supplies

Motor drives

Product Lifecycle

This product is currently in production and is not nearing discontinuation. Replacements and upgrades may be available in the future.

Several Key Reasons to Choose This Product

Integrated bootstrap circuit and regulator simplify design

High efficiency and low power consumption

Robust fault protection for reliable operation

Wide operating temperature range

Surface mount design for easy integration
