LMG3410R070RWHT - Texas Instruments

Manufacturer Part Number

LMG3410R070RWHT

Manufacturer

Texas Instruments

Introduction

High-efficiency, gallium nitride (GaN) power switch for advanced power conversion

Product Features and Performance

GaN technology for high power density and efficiency

Low on-resistance Rds(on) of 70mOhm for reduced conduction losses

Integrated bootstrap circuit for driving high-side N-channel MOSFETs

Features a 5V regulated output for additional circuitry

High load voltage capability up to 480V

PWM and logic compatible interface

Supports high switching frequencies

Product Advantages

Reduced system size due to small 32-VQFN package

Increased power conversion efficiency with GaN technology

Durable operation in a wide temperature range from -40°C to 125°C

Overcurrent and overtemperature protection for system safety

Under-voltage lockout (UVLO) feature for controlled operation

Key Technical Parameters

Power Management Category: Load Drivers

Single Output: 12A max current capacity

Supply Voltage (Vcc/Vdd): 9.5V to 18V

Rds On: 70mOhm typically

Output Type: N-Channel high side

Mounting Type: Surface Mount

Load Voltage: Up to 480V

Quality and Safety Features

Overcurrent protection

Temperature protection with a range of -40°C to 125°C

UVLO protects against low voltage conditions

Compatibility

Logic and PWM interface compatible

Surface mount design fits standard 32-VQFN footprint

Application Areas

Motor controllers

Power supplies

DC-DC converters

Electronic loads

Automotive and industrial power systems

Product Lifecycle

Product Status: Active

Not identified as nearing discontinuation

Replacements or upgrades may be available

Reasons to Choose This Product

High-efficiency GaN technology reduces power loss

Integrated protection features enhance system reliability

Accommodates high input voltage for diverse applications

Capable of operating within a wide temperature range

Enables high-current handling in a compact package

Multiple applications due to versatile power switch characteristics
