INA180A1IDBVT - Texas Instruments

Manufacturer Part Number

INA180A1IDBVT

Manufacturer

Texas Instruments

Introduction

High-precision, low-noise instrumentation amplifier

Designed for current sensing and monitoring applications

Product Features and Performance

Rail-to-rail output

Low input offset voltage of 100 µV

Low input bias current of 80 µA

High bandwidth of 350 kHz

Slew rate of 2 V/µs

Wide supply voltage range of 2.7 V to 5.5 V

Low power consumption of 260 µA

Product Advantages

Excellent precision and performance for current sensing

Wide operating temperature range of -40°C to 125°C

Small footprint in SOT-23-5 package

RoHS3 compliant

Key Technical Parameters

Manufacturer Part Number: INA180A1IDBVT

Package: SOT-23-5

Output Type: Rail-to-Rail

Mounting Type: Surface Mount

Operating Temperature: -40°C to 125°C

Supply Voltage Range: 2.7 V to 5.5 V

Supply Current: 260 µA

Slew Rate: 2 V/µs

Input Offset Voltage: 100 µV

Input Bias Current: 80 µA

-3dB Bandwidth: 350 kHz

Quality and Safety Features

RoHS3 compliant

Compatibility

Suitable for a wide range of current sensing and monitoring applications

Application Areas

Industrial equipment

Power supplies

Motor control

Battery management

Instrumentation and measurement systems

Product Lifecycle

This product is currently in production and widely available.

Replacements or upgrades may be available in the future as technology evolves.

Several Key Reasons to Choose This Product

Excellent precision and performance for current sensing applications

Wide operating temperature range and low power consumption

Small footprint in SOT-23-5 package

RoHS3 compliance for environmental sustainability

Compatibility with a wide range of current sensing and monitoring applications
