Manufacturer Part Number
CD4049UBF3A
Manufacturer
Texas Instruments
Introduction
Hex Inverter IC
Widely used in logic circuits and signal processing applications
Product Features and Performance
6 independent inverter circuits
Wide supply voltage range of 3V to 18V
Fast propagation delay of 90ns at 15V
Low quiescent current of 20μA
High and low level output current capability of 8mA and 48mA
Product Advantages
Versatile inverter functions
Wide operating voltage range
Low power consumption
Fast switching speed
Robust output drive capability
Key Technical Parameters
Number of Inputs: 6
Supply Voltage: 3V to 18V
Quiescent Current: 20μA (max)
Output Current (High/Low): 8mA / 48mA
Propagation Delay: 90ns @ 15V, 50pF
Operating Temperature: -55°C to 125°C
Quality and Safety Features
ROHS3 compliant
16-CDIP package for through-hole mounting
Compatibility
Widely compatible with various digital logic circuits and systems
Application Areas
General logic circuits
Signal processing
Analog-to-digital conversion
Timing and control applications
Product Lifecycle
Currently in production
No immediate plans for discontinuation
Replacements and upgrades available from Texas Instruments
Key Reasons to Choose
Versatile inverter functions
Wide operating voltage range
Low power consumption
Fast switching speed
Robust output drive capability
Proven reliability and performance from Texas Instruments
