Manufacturer Part Number
ADS1255IDBT
Manufacturer
Texas Instruments
Introduction
The ADS1255IDBT is a high-performance, 24-bit, delta-sigma analog-to-digital converter (ADC) from Texas Instruments.
Product Features and Performance
24-bit resolution
Sigma-delta architecture
Sampling rate up to 30kSPS
Configurable for 1 or 2 differential or single-ended inputs
Programmable gain amplifier (PGA) with up to 128x gain
Product Advantages
Excellent signal-to-noise ratio and low distortion
Wide operating temperature range of -40°C to 85°C
Low power consumption
Small 20-SSOP package
Key Technical Parameters
Supply voltage: 1.8V to 3.6V (digital), 5V (analog)
20-SSOP package
SPI digital interface
Quality and Safety Features
Compliant with RoHS3 directive
Robust, reliable, and long-lasting design
Compatibility
The ADS1255IDBT is compatible with a wide range of industrial, medical, and instrumentation applications.
Application Areas
Industrial process control
Medical instrumentation
Test and measurement equipment
Data acquisition systems
Product Lifecycle
The ADS1255IDBT is an actively supported product in Texas Instruments' portfolio. Replacement or upgrade options may be available.
Key Reasons to Choose This Product
High performance and precision with 24-bit resolution
Flexible configuration options with 1 or 2 inputs and programmable gain
Wide operating temperature range and low power consumption
Reliable and robust design with RoHS3 compliance
Compatibility with a wide range of applications
