NC4D-JP-DC24V - Panasonic Electric Works

Manufacturer Part Number: NC4D-JP-DC24V

Manufacturer: Panasonic

Allelco Part Number: 32D-NC4D-JP-DC24V

ECAD Model

Parts Description: RELAY GEN PURPOSE 4PDT 5A 24V

Detailed Description

Package

Data sheet: Cylindrical Battery Holders.pdf

RoHs Status: RoHS Compliant

~~Compare~~

In stock: 2578

Specifications

NC4D-JP-DC24V Tech Specifications
Panasonic Electric Works - NC4D-JP-DC24V technical specifications, attributes, parameters and parts with similar specifications to Panasonic Electric Works - NC4D-JP-DC24V

Product Attribute	Attribute Value
Manufacturer	Panasonic
Termination Style	PC Pin
Switching Voltage	250VAC - Max
Series	NC
Seal Rating	-
Release Time	10 ms
Relay Type	General Purpose
Package	Tube
Operating Temperature	-40°C ~ 55°C
Operate Time	20 ms
Must Release Voltage	2.4 VDC
Must Operate Voltage	19.2 VDC

Product Attribute	Attribute Value
Mounting Type	Through Hole
Features	-
Contact Rating (Current)	5 A
Contact Material	Silver Nickel (AgNi)
Contact Form	4PDT (4 Form C)
Coil Voltage	24VDC
Coil Type	Non Latching
Coil Resistance	800 Ohms
Coil Insulation	-
Coil Current	30 mA
Base Product Number	NC4D

Parts with Similar Specifications

The three parts on the right have similar specifications to Panasonic Electric Works NC4D-JP-DC24V

Product Attribute
Part Number	NC4D-JP-DC24V	AHN12105	DK1A1B-L2-3V	JC2AF-DC24V-F
Manufacturer	Panasonic Electric Works	Panasonic Electric Works	Panasonic Electric Works	Panasonic Electric Works
Release Time	10 ms	5 ms	8 ms	10 ms
Coil Type	Non Latching	Non Latching	Latching, Dual Coil	Non Latching
Series	NC	AHN	DK	JC
Coil Resistance	800 Ohms	47 Ohms	45 Ohms	576 Ohms
Coil Insulation	-	-	-	-
Contact Rating (Current)	5 A	16 A	8 A	10 A
Must Operate Voltage	19.2 VDC	3.5 VDC	2.1 VDC	19.2 VDC
Package	Tube	Box	Box	Tray
Relay Type	General Purpose	General Purpose	General Purpose	General Purpose
Coil Current	30 mA	106.4 mA	66.7 mA	41.6 mA
Operating Temperature	-40°C ~ 55°C	-40°C ~ 50°C	-40°C ~ 65°C	-50°C ~ 60°C
Termination Style	PC Pin	Plug In	PC Pin	PC Pin
Seal Rating	-	-	Sealed - Fully	-
Must Release Voltage	2.4 VDC	0.75 VDC	-	2.4 VDC
Operate Time	20 ms	15 ms	10 ms	30 ms
Coil Voltage	24VDC	5VDC	3VDC	24VDC
Switching Voltage	250VAC - Max	250VAC, 30VDC - Max	250VAC, 125VDC - Max	250VAC - Max
Features	-	Lighted Indicator	-	-
Contact Form	4PDT (4 Form C)	SPDT (1 Form C)	DPST-NO/NC (1 Form A, 1 Form B)	DPST-NO (2 Form A)
Contact Material	Silver Nickel (AgNi)	Silver Tin Oxide (AgSnO)	Silver Nickel (AgNi)	Silver Tin Oxide (AgSnO)
Mounting Type	Through Hole	Socketable	Through Hole	Through Hole
Base Product Number	NC4D	AHN121	DK1A	JC2AF

NC4D-JP-DC24V Datasheet PDF

Download NC4D-JP-DC24V pdf datasheets and Panasonic Electric Works documentation for NC4D-JP-DC24V - Panasonic Electric Works.

Datasheets: Cylindrical Battery Holders.pdf
Other Related Documents: How to Read Date Codes.pdf General Appl Guidelines.pdf Standards Chart.pdf
PCN Packaging: 2.73KHz.pdf
