Manufacturer Part Number
MPQ8904DD-AEC1-LF-Z
Manufacturer
Monolithic Power Systems
Introduction
The MPQ8904DD-AEC1-LF-Z is a low drop-out (LDO) linear voltage regulator designed for automotive applications, providing adjustable output from an input up to 6.5V.
Product Features and Performance
Adjustable output voltage from 0.5V to 5V
Maximum output current of 500mA
Low dropout voltage of 0.45V at 500mA load
Features include enable and power good signals
Overcurrent and overtemperature protection
Operates from -40°C to 125°C
Product Advantages
High efficiency suitable for automotive use
Robust thermal performance and reliability
Low quiescent current of 200 µA optimizing battery life
Key Technical Parameters
Input Voltage (Max): 6.5V
Output Voltage (Min/Fixed): 0.5V
Output Voltage (Max): 5V
Dropout Voltage (Max): 0.45V @ 500mA
Output Current: 500mA
Quiescent Current (Iq): 200 µA
Quality and Safety Features
Over Current and Over Temperature Protection
Automotive-grade qualification by AEC-Q100
Compatibility
Compatible with various automotive applications requiring efficient voltage regulation
Application Areas
Automotive electronics
Battery-powered devices
Portable electronics
Product Lifecycle
Status: Active
No impending discontinuation, with readily available replacements and upgrades
Several Key Reasons to Choose This Product
Flexible and adjustable output for diverse automotive needs
High reliability and safety features ideal for harsh automotive environments
Extended operating temperature range suitable for extreme conditions
Low power consumption enhancing overall system efficiency
