Manufacturer Part Number
APT8024JLL
Manufacturer
Microchip Technology
Introduction
High-performance N-channel power MOSFET for switching applications
Product Features and Performance
Capable of operating at high voltages up to 800V
Low on-resistance of 240mOhm @ 14.5A, 10V
High continuous drain current of 29A at 25°C
Wide operating temperature range of -55°C to 150°C
Low input capacitance of 4670pF @ 25V
High power dissipation capability of 460W
Product Advantages
Excellent high-voltage switching performance
Efficient power conversion due to low on-resistance
Reliable operation in high-temperature environments
Compact ISOTOP package for easy integration
Key Technical Parameters
Drain to Source Voltage (Vdss): 800V
Gate-Source Voltage (Vgs) Max: ±30V
Drain Current (Id) Continuous @ 25°C: 29A
On-Resistance (Rds(on)) Max: 240mOhm
Input Capacitance (Ciss) Max: 4670pF
Power Dissipation (Pd) Max: 460W
Quality and Safety Features
MOSFET technology for high reliability and ruggedness
Designed and manufactured to meet industrial-grade quality standards
Compatibility
Suitable for a wide range of high-voltage switching applications
Application Areas
Switch-mode power supplies
Motor drives
Industrial electronics
Renewable energy systems
Product Lifecycle
This product is currently in active production and not nearing discontinuation
Replacement or upgraded products may become available in the future as technology evolves
Key Reasons to Choose This Product
Excellent high-voltage switching performance
Efficient power conversion due to low on-resistance
Reliable operation in high-temperature environments
Compact package for easy integration
Designed and manufactured to meet industrial-grade quality standards
