WL1801MODGBMOCR - Texas Instruments

Manufacturer Part Number

WL1801MODGBMOCR

Manufacturer

Texas Instruments

Introduction

This product is a high-performance RF transceiver module that supports both Bluetooth and Wi-Fi connectivity.

Product Features and Performance

Supports Bluetooth 4.2 and 802.11b/g/n Wi-Fi protocols

Frequency range of 2.4GHz

Operating temperature range of -20°C to 70°C

Power output of 17.3dBm

Receiver sensitivity of -96.3dBm

Data rates up to 54Mbps

Supports SDIO and UART serial interfaces

Product Advantages

Compact 100-SMD module design

Wide operating voltage range of 2.9V to 4.8V

Low current consumption during transmit (238mA to 420mA) and receive (49mA to 85mA) modes

Key Technical Parameters

Frequency: 2.4GHz

Modulation: CCK, DSSS, GFSK, OFDM

Voltage Supply: 2.9V to 4.8V

Mounting Type: Surface Mount

Quality and Safety Features

RoHS3 compliant

Compatibility

Compatible with various Bluetooth and Wi-Fi enabled devices

Application Areas

Suitable for a wide range of wireless connectivity applications, such as IoT devices, embedded systems, and wireless peripherals.

Product Lifecycle

Currently available, with no known plans for discontinuation.

Key Reasons to Choose This Product

High-performance RF transceiver module supporting both Bluetooth and Wi-Fi

Compact and low-power design

Wide operating temperature and voltage range

Extensive compatibility with various wireless devices and applications
