UCD7100PWPR - Texas Instruments

Manufacturer Part Number

UCD7100PWPR

Manufacturer

Texas Instruments

Introduction

MOSFET Gate Driver

Product Features and Performance

Single-channel MOSFET gate driver

Capable of driving N-channel MOSFETs

Supports input voltage range of 4.25V to 15V

Fast rise and fall times of 10ns (typical)

Peak output current of 4A (source and sink)

Operates over a wide temperature range of -40°C to 105°C

Product Advantages

Optimized for high-speed, high-current MOSFET switching

Compact 14-HTSSOP package

Suitable for a wide range of power management applications

Key Technical Parameters

Input Type: Non-Inverting

Channel Type: Single

Driven Configuration: Low-Side

Gate Type: N-Channel MOSFET

Logic Voltage (VIL, VIH): 1.16V, 2.08V

Quality and Safety Features

RoHS3 compliant

Compatibility

Surface mount package (14-PowerTSSOP)

Application Areas

Power management

Motor control

Power conversion

Industrial automation

Product Lifecycle

This product is currently available and not nearing discontinuation.

Replacements and upgrades may be available from Texas Instruments or other manufacturers.
