UCC27282DRCR - Texas Instruments

Manufacturer Part Number

UCC27282DRCR

Manufacturer

Texas Instruments

Introduction

The UCC27282DRCR is a high-performance power management integrated circuit (PMIC) designed specifically for driving N-Channel MOSFETs in a half-bridge configuration. It is utilized in various applications, including power supplies and motor control systems.

Product Features and Performance

Dual-channel independent half-bridge gate driver

Supports N-Channel MOSFETs

Supply voltage range from 5.5V to 16V

Logic level thresholds for high ease of interfacing: VIH = 2.4V, VIL = 0.9V

High peak output current capability: 2.5A source, 3.5A sink

Fast rise and fall times: 12ns and 10ns respectively

High side voltage tolerance up to 120V (Bootstrap)

Operates over a temperature range of -40°C to 125°C

Surface mount package for compact designs

Product Advantages

Enhanced reliability for driving MOSFETs in high-side and low-side configurations

Flexible power supply requirements accommodate a broad range of applications

Fast switching capabilities minimize power losses and improve efficiency

Robust temperature performance ensures reliability in harsh environments

Key Technical Parameters

Driven Configuration: Half-Bridge

Number of Drivers: 2

Voltage Supply: 5.5V ~ 16V

Current Peak Output: 2.5A (Source), 3.5A (Sink)

High Side Voltage Max (Bootstrap): 120V

Rise / Fall Time: 12ns / 10ns

Operating Temperature: -40°C ~ 125°C

Quality and Safety Features

Stringent quality control measures during manufacturing

Built-in protection mechanisms for extended reliability

Compatibility

Ideal for a wide range of N-Channel MOSFET applications

Easily interfaced with various logic levels

Application Areas

Power supply units

Motor control systems

Switching power supplies

Renewable energy systems

Product Lifecycle

Currently in active production with no imminent discontinuation

Availability of replacements or upgrades is guaranteed

Several Key Reasons to Choose This Product

High reliability and performance verified by Texas Instruments' rigorous testing

Versatile power supply compatibility and logic level thresholds for diverse applications

Fast switching speeds for improved power efficiency and reduced losses

Robust design capable of operating in extreme temperatures

Comprehensive feature set makes it ideal for a wide range of power management tasks
