HomeProductsIntegrated Circuits (ICs)PMIC - Voltage Regulators - LinearTPS799185DDCR
TPS799185DDCR Image
TPS799185DDCR Image - 1
Image may be representation.
See specifications for product details.
Share
 Favorite
EXPRESS OPTION
Payment method

TPS799185DDCR - Texas Instruments

Manufacturer Part Number
TPS799185DDCR
Manufacturer
Texas Instruments
Allelco Part Number
32D-TPS799185DDCR
ECAD Model
Parts Description
IC REG LIN 1.85V 200MA SOT23-5
Package
SOT-23-5 Thin, TSOT-23-5
Data sheet
TPS799185DDCR.pdf
RoHs Status
ROHS3 Compliant
Compare
Our certification
In stock: 137500

Required fields are indicated by an asterisk (*)
Please send RFQ, we will respond immediately.

Quantity
EXPRESS OPTION
Payment method
Our certification

Specifications

TPS799185DDCR Tech Specifications
Texas Instruments - TPS799185DDCR technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - TPS799185DDCR

Product Attribute Attribute Value
Manufacturer Texas Instruments
Voltage Dropout (Max) 0.18V @ 200mA
Voltage - Output (Min/Fixed) 1.85V
Voltage - Output (Max) -
Voltage - Input (Max) 6.5V
Supplier Device Package SOT-23-THIN
Series -
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Package / Case SOT-23-5 Thin, TSOT-23-5
Package Tape & Reel (TR)
Product Attribute Attribute Value
PSRR 70dB ~ 38dB (100Hz ~ 100kHz)
Output Type Fixed
Output Configuration Positive
Operating Temperature -40°C ~ 125°C
Number of Regulators 1
Mounting Type Surface Mount
Current - Quiescent (Iq) 60 µA
Current - Output 200mA
Control Features Enable
Base Product Number TPS799185

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHs Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001

Parts Introduction

Manufacturer Part Number

TPS799185DDCR

Manufacturer

Texas Instruments

Introduction

The TPS799185DDCR is a high-performance, low-dropout linear voltage regulator.

Product Features and Performance

Low dropout: 0.18V @ 200mA

Fixed output voltage: 1.85V

Output current: 200mA

High PSRR: 70dB @ 100Hz to 38dB @ 100kHz

Quiescent current: 60 µA

Product Advantages

High power supply rejection ratio (PSRR)

Low quiescent current for power saving

Stable with low ESR capacitors

Fast transient response

Key Technical Parameters

Input voltage (max): 6.5V

Output voltage (min/fixed): 1.85V

Dropout voltage (max): 0.18V @ 200mA

Output current: 200mA

Quiescent current (Iq): 60 µA

Power Supply Rejection Ratio (PSRR): 70dB ~ 38dB (100Hz ~ 100kHz)

Quality and Safety Features

Overcurrent protection

Overtemperature protection

Reverse polarity protection

Under Voltage Lockout (UVLO)

Compatibility

Compatible with ceramic, tantalum, and aluminum electrolytic capacitors

Supports SOT-23-5 Thin, TSOT-23-5 package footprint

Application Areas

Power-sensitive applications

Battery-powered devices

Portable and handheld instruments

Product Lifecycle

Active status

Not nearing discontinuation

Availability for replacements or upgrades

Several Key Reasons to Choose This Product

High-efficiency voltage regulation for longer battery life

Robust protection features ensuring product longevity

Small form factor for space-constrained applications

Texas Instruments quality and support

Broad application flexibility with fixed output voltage

Parts with Similar Specifications

The three parts on the right have similar specifications to Texas Instruments TPS799185DDCR

Product Attribute TPS799185DDCR TPS79918DDCR TPS79913YZUR TPS79915DDCR
Part Number TPS799185DDCR TPS79918DDCR TPS79913YZUR TPS79915DDCR
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Number of Regulators 1 1 1 1
Output Type Fixed Fixed Fixed Fixed
Output Configuration Positive Positive Positive Positive
Voltage - Input (Max) 6.5V 6.5V 6.5V 6.5V
Package / Case SOT-23-5 Thin, TSOT-23-5 SOT-23-5 Thin, TSOT-23-5 5-UFBGA, DSBGA SOT-23-5 Thin, TSOT-23-5
PSRR 70dB ~ 38dB (100Hz ~ 100kHz) 70dB ~ 38dB (100Hz ~ 100kHz) 70dB ~ 38dB (100Hz ~ 100kHz) 70dB ~ 38dB (100Hz ~ 100kHz)
Current - Quiescent (Iq) 60 µA 60 µA 60 µA 60 µA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Voltage - Output (Max) - - - -
Package Tape & Reel (TR) Tape & Reel (TR) Tape & Reel (TR) Tape & Reel (TR)
Base Product Number TPS799185 TPS79918 TPS79913 TPS79915
Operating Temperature -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C
Control Features Enable Enable Enable Enable
Series - - - -
Voltage - Output (Min/Fixed) 1.85V 1.8V 1.3V 1.5V
Voltage Dropout (Max) 0.18V @ 200mA 0.18V @ 200mA 0.18V @ 200mA 0.18V @ 200mA
Current - Output 200mA 200mA 200mA 200mA
Supplier Device Package SOT-23-THIN SOT-23-THIN 5-DSBGA SOT-23-THIN
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount
