TPS561201DDCR - Texas Instruments

Manufacturer Part Number

TPS561201DDCR

Manufacturer

Texas Instruments

Introduction

The TPS561201DDCR is a step-down (buck) regulator from Texas Instruments, designed for power management applications, featuring adjustable output voltage and high efficiency.

Product Features and Performance

Adjustable output voltage from 0.76V to 7V

Capable of delivering output current up to 1A

Synchronous rectification for improved efficiency

Wide input voltage range from 4.5V to 17V

Switching frequency of 580kHz

Operating temperature range from -40°C to 125°C

Product Advantages

High efficiency due to synchronous rectification

Flexible power solution with adjustable output

Compact package suitable for space-constrained applications

Key Technical Parameters

Voltage Input (Min): 4.5V

Voltage Input (Max): 17V

Voltage Output (Min/Fixed): 0.76V

Voltage Output (Max): 7V

Current Output: 1A

Frequency Switching: 580kHz

Operating Temperature: -40°C ~ 125°C

Quality and Safety Features

Built-in thermal shutdown protection

Overcurrent protection

Safe operating area protection

Compatibility

Compatible with a wide range of input voltages

Suitable for various applications due to adjustable output voltage

Application Areas

Consumer Electronics

Telecommunications

Computing Systems

Power Management Solutions

Product Lifecycle

Active status, not nearing discontinuation

Availability of replacements or upgrades is ensured by Texas Instruments

Several Key Reasons to Choose This Product

High efficiency and reliability from a leading manufacturer in power management

Wide input voltage range allows for versatile applications across different power systems

Adjustable output voltage provides design flexibility

Compact size for space-sensitive applications

Comprehensive protection features ensure long-term reliability and safety
