TPS55010RTER - Texas Instruments

Manufacturer Part Number

TPS55010RTER

Manufacturer

Texas Instruments

Introduction

Integrated Circuits (ICs)

PMIC Voltage Regulators DC DC Switching Regulators

Product Features and Performance

RoHS3 Compliant

16-WQFN (3x3) package

Adjustable output

Surface mount

Operating temperature range: -40°C to 150°C

Tape & Reel (TR) packaging

Output voltage: 3.3V to 20V

Single output

Positive or negative output, isolation capable

Synchronous rectifier

Switching frequency: 100kHz to 2MHz

Flyback topology

Step-up/step-down function

Input voltage range: 2.98V to 6V

Product Advantages

Wide operating temperature range

Adjustable output voltage

Isolation capable

Synchronous rectifier for improved efficiency

Wide switching frequency range

Key Technical Parameters

Package: 16-WFQFN Exposed Pad

Mounting type: Surface mount

Number of outputs: 1

Output configuration: Positive or negative, isolation capable

Synchronous rectifier: Yes

Switching frequency: 100kHz to 2MHz

Topology: Flyback

Output voltage: 3.3V to 20V

Input voltage: 2.98V to 6V

Quality and Safety Features

RoHS3 compliant

Compatibility

Compatible with a wide range of electronic systems and devices

Application Areas

Suitable for various power conversion applications that require a step-up/step-down function, such as industrial, medical, and consumer electronics

Product Lifecycle

The TPS55010 is an active product and not nearing discontinuation.

Replacements and upgrades may be available from Texas Instruments.

Key Reasons to Choose This Product

Wide operating temperature range (-40°C to 150°C)

Adjustable output voltage for flexibility

Isolation capability for safety-critical applications

Synchronous rectifier for improved efficiency

Wide switching frequency range for design flexibility

RoHS3 compliance for environmental responsibility
