TPS54917RUVR Image
TPS54917RUVR Image - 1
Image may be representation.
See specifications for product details.
Share
 Favorite

TPS54917RUVR - Texas Instruments

Manufacturer Part Number
TPS54917RUVR
Manufacturer
Texas Instruments
Allelco Part Number
32D-TPS54917RUVR
ECAD Model
Parts Description
IC REG BUCK ADJUSTABLE 9A 34VQFN
Detailed Description
Package
34-VFQFN Exposed Pad
Data sheet
TPS54917.pdf
RoHs Status
ROHS3 Compliant
Compare
In stock: 8070

Required fields are indicated by an asterisk (*)
Please send RFQ, we will respond immediately.

Quantity

Specifications

TPS54917RUVR Tech Specifications
Texas Instruments - TPS54917RUVR technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - TPS54917RUVR

Product Attribute Attribute Value
Manufacturer Texas Instruments
Voltage - Output (Min/Fixed) 0.891V
Voltage - Output (Max) 3.6V
Voltage - Input (Min) 3V
Voltage - Input (Max) 4V
Topology Buck
Synchronous Rectifier Yes
Supplier Device Package 34-VQFN (7x3.5)
Series SWIFT™
Package / Case 34-VFQFN Exposed Pad
Product Attribute Attribute Value
Package Tape & Reel (TR)
Output Type Adjustable
Output Configuration Positive
Operating Temperature -40°C ~ 125°C (TJ)
Number of Outputs 1
Mounting Type Surface Mount
Function Step-Down
Frequency - Switching 350kHz, 550kHz
Current - Output 9A
Base Product Number TPS54917

Parts Introduction

Manufacturer Part Number

TPS54917RUVR

Manufacturer

Texas Instruments

Introduction

High-Efficiency, Synchronous Step-Down SWIFT™ Converter

Product Features and Performance

Fully Integrated Synchronous Buck Converter

350 kHz and 550 kHz Switching Frequency

Up to 9A Output Current

Adjustable Output Voltage from 0.891V to 3.6V

Integrated High-Side and Low-Side MOSFETs

Cycle-by-Cycle Current Limit

Thermal Shutdown Protection

TSNS Pin for Accurate Remote Voltage Sensing

Product Advantages

High Efficiency over Wide Load Range

Compact Solution Size

Robust Protection Features

Flexible Output Voltage Configuration

Key Technical Parameters

Input Voltage Range: 3V to 4V

Output Voltage Range: 0.891V to 3.6V

Output Current: Up to 9A

Switching Frequency: 350 kHz, 550 kHz

Operating Temperature: -40°C to 125°C

Quality and Safety Features

ROHS3 Compliant

Integrated Protection Features (Overcurrent, Thermal Shutdown)

Compatibility

Suitable for a Wide Range of Applications that Require a Compact, Efficient, and Robust Power Supply

Application Areas

Portable Electronics

Industrial Equipment

Telecommunications Equipment

Automotive Electronics

Product Lifecycle

Currently in Production

Replacements and Upgrades Available

Several Key Reasons to Choose This Product

Excellent Efficiency and Power Density

Robust Protection Features

Flexible Output Voltage Configuration

Wide Operating Temperature Range

Compact Solution Size

Proven Performance in a Variety of Applications

Parts with Similar Specifications

The three parts on the right have similar specifications to Texas Instruments TPS54917RUVR

Product Attribute TPS54917RUVR TPS54917RUVT TPS548D21RVFT TPS548D22RVFR
Part Number TPS54917RUVR TPS54917RUVT TPS548D21RVFT TPS548D22RVFR
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Voltage - Input (Max) 4V 4V 16V 16V
Voltage - Output (Min/Fixed) 0.891V 0.891V 0.6V 0.6V
Number of Outputs 1 1 1 1
Voltage - Output (Max) 3.6V 3.6V 5.5V 5.5V
Function Step-Down Step-Down Step-Down Step-Down
Base Product Number TPS54917 TPS54917 TPS548D21 TPS548D22
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount
Operating Temperature -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ)
Frequency - Switching 350kHz, 550kHz 350kHz, 550kHz Selectable Selectable
Synchronous Rectifier Yes Yes Yes Yes
Series SWIFT™ SWIFT™ SWIFT™, D-CAP3™, Eco-Mode™ SWIFT™, D-CAP3™, Eco-Mode™
Package / Case 34-VFQFN Exposed Pad 34-VFQFN Exposed Pad 40-PowerLFQFN 40-PowerLFQFN
Current - Output 9A 9A 40A 40A
Topology Buck Buck Buck Buck
Output Configuration Positive Positive Positive Positive
Supplier Device Package 34-VQFN (7x3.5) 34-VQFN (7x3.5) 40-LQFN-CLIP (7x5) 40-LQFN-CLIP (7x5)
Voltage - Input (Min) 3V 3V 1.5V 1.5V
Package Tape & Reel (TR) Tape & Reel (TR) Tape & Reel (TR) Tape & Reel (TR)
Output Type Adjustable Adjustable Adjustable Adjustable

TPS54917RUVR Datasheet PDF
