TPS2069DGNR - Texas Instruments

Manufacturer Part Number

TPS2069DGNR

Manufacturer

texas-instruments

Introduction

The TPS2069DGNR by Texas Instruments is a power management integrated circuit (PMIC) specifically designed for power distribution and load driving. Suited for a broad range of applications, this chip facilitates controlled power distribution to downstream circuits.

Product Features and Performance

Single output high-side N-Channel power distribution switch

Current limiting (Fixed), over-temperature protection, reverse current protection, and UVLO (Under Voltage Lock Out)

Interface: On/Off control for easy application integration

Status flag output for real-time operating feedback

Rds On (Typical) of 70mOhm

Product Advantages

Integrated fault protection enhances system reliability

Low Rds On reduces power dissipation

Compact 8-HVSSOP package saves board space

Status flag enables intelligent power management

Key Technical Parameters

Voltage Load: 2.7V to 5.5V

Current Output (Max): 1.5A

Operating Temperature: -40°C to +105°C

Packaging: Tape & Reel (TR) for efficient assembly processing

Mounting Type: Surface Mount

Quality and Safety Features

Over-temperature protection prevents damage from overheating

Current limiting safeguards against overcurrent conditions

Reverse current protection protects against backward current flow

UVLO prevents operation under unsafe voltage conditions

Compatibility

Compatible with a wide voltage range (2.7V to 5.5V), supporting various applications

Suitable for use in systems requiring an on/off control interface

Application Areas

USB hubs, peripherals, and ports

Battery-charged devices

Consumer electronics

Portable equipment

Product Lifecycle

Status: Active, ensuring ongoing production and availability

Not nearing discontinuation, with replacements and upgrades continuously developed

Several Key Reasons to Choose This Product

Texas Instruments' reliability and support

Broad compatibility with various voltages and interfaces

Compact package suitable for space-constrained applications

Comprehensive protection features ensure product longevity

Proven application performance in consumer and portable electronics
