TPS2061CDGNR - Texas Instruments

Manufacturer Part Number

TPS2061CDGNR

Manufacturer

Texas Instruments

Introduction

The TPS2061CDGNR is a power distribution switch from Texas Instruments, designed primarily for USB applications, ensuring efficient power management and device protection.

Product Features and Performance

Single USB switch

High side output configuration with N-Channel output type

Integrated output discharge

Features fault protection including current limiting, over temperature protection, reverse current protection, and under-voltage lockout (UVLO)

Product Advantages

Provides robust protection for connected devices

Simplifies power management in USB applications

Compact 8-HVSSOP package suitable for space-sensitive applications

Key Technical Parameters

Voltage Load: 4.5V ~ 5.5V

Current Output (Max): 1A

Rds On (Typ): 86mOhm

Operating Temperature: -40°C ~ 85°C (TA)

Quality and Safety Features

Fault protection mechanisms protect against overcurrent, excessive temperature, reverse current, and voltage drops

Designed for reliable operation in a wide range of temperatures

Compatibility

Compatible with 4.5V to 5.5V load voltages ideal for standard USB powered devices

Application Areas

USB hubs, docks, and charging stations

Power management solutions in consumer electronics

Product Lifecycle

Currently active with ongoing manufacturer support

Not nearing discontinuation, ensuring long-term availability and support

Several Key Reasons to Choose This Product

Reliable fault protection enhances device safety and longevity

Support for a broad operating temperature range fits various environments

Texas Instruments' reputation for high-quality and durable components

Optimal performance in managing and distributing USB power
