Manufacturer Part Number
TPS2051BDGNR
Manufacturer
Texas Instruments
Introduction
The TPS2051BDGNR is a high-performance power distribution switch designed for power management applications.
Product Features and Performance
Single channel output
High side output configuration
N-Channel output type
Non-inverting input type
Supports on/off interface
Load voltage range from 2.7V to 5.5V
Current limiting, over temperature protection, and under-voltage lockout for safety
Surface mount design
Product Advantages
Provides reliable and precise control in power management
Integrates multiple safety features to ensure device and system safety
Compact form factor and simplicity in usage
Key Technical Parameters
Output: 1
Voltage Load: 2.7V ~ 5.5V
Current Output (Max): 500mA
Rds On (Typ): 70mOhm
Operating temperature: -40°C ~ 85°C
Quality and Safety Features
Current limiting (Fixed)
Over temperature protection
Under-voltage lockout (UVLO)
Compatibility
Compatible with a variety of loads within its specified voltage and current ranges
Application Areas
Consumer Electronics
Telecommunication systems
Computer peripherals
Industrial controls
Product Lifecycle
Status: Active
Not currently nearing discontinuation
Replacements and upgrades are available as per market technology advancements
Several Key Reasons to Choose This Product
Reliable operation within a broad range of temperatures (-40°C ~ 85°C)
Efficient power distribution with typical Rds of 70mOhm
Built-in fault protection features enhance device longevity and safety
High compatibility with standard voltage and current levels used in various applications
Available in a compact package suitable for space-constrained applications
Active product lifecycle with ongoing support and availability of upgrades
