TPD4EUSB30DQAR - Texas Instruments

Manufacturer Part Number

TPD4EUSB30DQAR

Manufacturer

Texas Instruments

Introduction

The TPD4EUSB30DQAR by Texas Instruments is a Transient Voltage Suppressor (TVS) diode, designed for general purpose applications. It provides protection for sensitive electronics from voltage spikes and transients.

Product Features and Performance

Steering (Rail to Rail) TVS type

Four unidirectional channels

Reverse Standoff Voltage: 5.5V max

Breakdown Voltage: Min 7V

Clamping Voltage: Max 8V @ Ipp

Peak Pulse Current: 1A (8/20µs)

Peak Pulse Power: 45W

Power Line Protection: Yes

Operating Temperature range: -40°C to 85°C

Surface Mount, 10-UFDFN package

Product Advantages

Provides robust protection against voltage transients

Multi-channel protection in a compact package

Versatile protection suitable for a wide range of applications

Efficient at dissipating transient energies

Key Technical Parameters

Voltage Reverse Standoff (Typ): 5.5V

Voltage Breakdown (Min): 7V

Voltage Clamping (Max): 8V @ Ipp

Current Peak Pulse: 1A (8/20µs)

Power Peak Pulse: 45W

Quality and Safety Features

Engineered to meet stringent standards for reliability and performance

Designed for high durability and long service life

Compatibility

Compatible with a wide range of electronic devices requiring voltage transient protection

Application Areas

General Purpose applications across various industries

Ideal for protecting sensitive electronics in consumer, automotive, and industrial sectors

Product Lifecycle

Status: Active

Not reported as nearing discontinuation, replacements or upgrades readily available

Several Key Reasons to Choose This Product

High reliability and performance from a trusted manufacturer, Texas Instruments

Compact and efficient design offers versatile protection in a small footprint

Robust protection capabilities enhance the longevity and durability of connected devices

Suitable for a broad spectrum of applications, enhancing its utility for designers

Active product status ensures availability and support for ongoing and future projects
