TMS320F2812PGFS - Texas Instruments

Manufacturer Part Number

TMS320F2812PGFS

Manufacturer

Texas Instruments

Introduction

The TMS320F2812PGFS is a high-performance, 32-bit microcontroller designed for advanced control applications. It is part of Texas Instruments' C2000™ C28x Fixed-Point Series, optimized for processing efficiency and operational speed.

Product Features and Performance

32-bit C28x core processor running at 150MHz

Advanced control law accelerator (CLA) for accelerated processing

256KB of FLASH memory and 18KB of RAM

Connectivity options include CANbus, EBI/EMI, McBSP, SCI, SPI, and UART/USART

Peripherals: DMA, Power-on Reset (POR), Pulse Width Modulation (PWM), Watchdog Timer (WDT)

Analog to Digital Converters: 16 channels, 12-bit resolution

Internal oscillator for reliability

Product Advantages

High-speed operation facilitating complex algorithm execution

Extensive connectivity and peripherals support diverse application needs

Robust voltage supply range and operational temperature scope enhance versatility in harsh conditions

Automotive grade quality ensuring reliability and durability

Key Technical Parameters

Core Size: 32-Bit Single-Core

Speed: 150 MHz

Program Memory Size: 256KB (128K x 16)

RAM Size: 18K x 16

Number of I/O: 56

Voltage Supply: 1.81V ~ 2V

Operating Temperature: -40°C ~ 125°C

Quality and Safety Features

AEC-Q100 qualified for automotive applications

Rigorous internal oscillator for steady operation

Enhanced watchdog timer for system safety

Compatibility

Compatible with a variety of industry-standard communication and interface protocols

Easy integration with various peripherals and external components

Surface mount technology for streamlined PCB design and manufacturing

Application Areas

Automotive engine management

Industrial motor control

Power tools and applications requiring precise control and high-speed data processing

Product Lifecycle

Product status: Active

Not currently nearing discontinuation

Ongoing support and updates available

Several Key Reasons to Choose This Product

Exceptional processing power for real-time control applications

Comprehensive set of peripherals and connectivity options increase design flexibility

Durable and reliable performance in automotive and industrial environments

Strong support and longevity in the market as part of Texas Instruments' trusted product line

Meets stringent automotive industry standards for quality and safety
