Manufacturer Part Number
TMS320F28069MPNT
Manufacturer
texas-instruments
Introduction
The TMS320F28069MPNT is part of the texas-instruments C2000™ C28x Piccolo™ series, specialized for high-performance embedded microcontroller solutions. Ideal for a wide range of applications requiring precise control and processing power within an efficient, compact package.
Product Features and Performance
32-Bit Single-Core C28x processing core with a speed of 90MHz.
Enhanced control peripherals including Brown-out Detect/Reset, DMA, POR, PWM, WDT.
40 I/O pins for versatile connectivity and functionality.
256KB of FLASH memory and 50K x 16 RAM for substantial program and data storage.
Advanced connectivity with CANbus, I2C, McBSP, SCI, SPI, UART/USART interfaces.
12x12b A/D converters for precise analog to digital conversion.
Internal oscillator for reliable timing.
Operates across a wide temperature range of -40°C ~ 105°C.
Product Advantages
High processing power with low power consumption.
Comprehensive peripheral set enhances system control capabilities.
Flexible I/O options and connectivity cater to a wide range of application needs.
Large program and data memory support complex algorithms and functionalities.
Exceptional analog to digital conversion accuracy.
Robust operation in extreme conditions.
Key Technical Parameters
Core Processor: C28x
Core Size: 32-Bit Single-Core
Speed: 90MHz
Program Memory Size: 256KB (128K x 16)
Program Memory Type: FLASH
RAM Size: 50K x 16
Voltage Supply (Vcc/Vdd): 1.71V ~ 1.995V
Operating Temperature: -40°C ~ 105°C
Quality and Safety Features
Includes Brown-out Detect/Reset and POR for system reliability.
Watchdog Timer (WDT) for system integrity.
Manufactured to operate reliably in extreme temperatures.
Compatibility
Supports a variety of digital and analog connectivity options for broad peripheral and sensor compatibility.
Surface Mount, 80-LQFP packaging compatible with standard assembly processes.
Application Areas
Industrial Control Systems
Automotive Control Systems
Power Management
Telecommunications
Robotics
Product Lifecycle
Active Product Status, not currently nearing discontinuation.
Ongoing support and availability of replacements or upgrades.
Several Key Reasons to Choose This Product
High-performance C28x core optimized for embedded control applications.
Comprehensive suite of peripherals enhances design flexibility and functionality.
Robust memory configuration supports complex applications and algorithms.
Superior analog conversion capabilities enable precise measurement and control.
Durable and reliable operation in harsh environments.
Ongoing product lifecycle support from texas-instruments ensures future-proofing of designs.
