Manufacturer Part Number
TLV809EC26DBZR
Manufacturer
Texas Instruments
Introduction
Voltage supervisor designed for system voltage monitoring and reset function implementation
Product Features and Performance
Simple Reset/Power-On Reset functionality
Monitors one voltage level
Active low reset signal
Push-Pull, Totem Pole output configuration
Minimum reset timeout duration of 6.5ms
Product Advantages
High-temperature operational capability up to 125°C
Small form factor with SOT-23-3 package for space-saving applications
Key Technical Parameters
Voltage Threshold: 2.64V
Number of Voltages Monitored: 1
Operating Temperature Range: -40°C to 125°C
Reset Timeout Period: 6.5ms minimum
Quality and Safety Features
Robust operation in extreme temperature conditions
Compatibility
Compatible with various microcontroller and processor setups requiring voltage supervision
Application Areas
Automotive systems
Embedded systems
Data storage devices
Computing and telecom infrastructure
Product Lifecycle
Active product status, not near discontinuation
Availability of replacements or upgrades can be referenced through Texas Instruments’ product family
Key Reasons to Choose This Product
Precision voltage monitoring for stable system operation
Extended temperature range suitable for harsh environments
Compact package ideal for high-density electronic boards
Reliable reset signal generation ensuring proper system initialization
From a reputable semiconductor manufacturer with broad support and resources
