TLV70530YFPR - Texas Instruments

Manufacturer Part Number

TLV70530YFPR

Manufacturer

Texas Instruments

Introduction

The TLV70530YFPR is a high-performance low-dropout linear voltage regulator, specifically designed for power-sensitive applications requiring a stable and clean power supply.

Product Features and Performance

Delivers an output of 3V from a maximum input of 5.5V

Supports up to 200mA output current

Very low dropout voltage: 0.25V at 200mA load

Excellent Power Supply Rejection Ratio: 80dB ~ 55dB (10kHz ~ 1MHz)

Enable control features for power management

Operates efficiently with a quiescent current of 55 µA

Product Advantages

High efficiency and low quiescent current ideal for power-sensitive applications

Robust protection features (Over Current, Over Temperature, Reverse Polarity, UVLO)

Compact 4-XFBGA, DSBGA package allows for smaller board footprint

Key Technical Parameters

Input Voltage (Max): 5.5V

Output Voltage (Min/Fixed): 3V

Current - Output: 200mA

Dropout Voltage (Max): 0.25V @ 200mA

Quiescent Current (Iq): 55 µA

Current - Supply (Max): 315 µA

Quality and Safety Features

Over Current Protection

Over Temperature Protection

Reverse Polarity Protection

Under Voltage Lockout (UVLO)

Compatibility

Compatible with a wide variety of applications due to stable output and compact packaging

Application Areas

Ideal for battery-powered devices, IoT devices, and portable electronics

Product Lifecycle

Currently active with no announced discontinuation. Replacements and upgrades available as technology progresses.

Several Key Reasons to Choose This Product

Ultra-low dropout for effective power utilization

Extended protection mechanisms enhance device longevity

Supports a broad range of applications from consumer electronics to industrial devices

High PSRR ensures cleaner and more stable output voltage

Long product lifecycle with support for future technological upgrades
