TLV3401CDBVT - Texas Instruments

Manufacturer Part Number

TLV3401CDBVT

Manufacturer

Texas Instruments

Introduction

High-precision general-purpose linear comparator designed for voltage detection and signal processing applications.

Product Features and Performance

General-Purpose linear comparator

Single element configuration

CMOS, Open-Drain output type

Supports both single and dual power supply voltages

Low input offset voltage

Ultra-low input bias current

CMRR (Common-Mode Rejection Ratio)

PSRR (Power Supply Rejection Ratio)

Extended operating temperature range

Product Advantages

High precision with maximal 3.6mV input offset voltage

Low power consumption with quiescent current under 950nA

High output current capability up to 10mA

Excellent noise immunity with 88dB CMRR and 105dB PSRR

Suitable for battery-powered applications due to low operating voltage range

Key Technical Parameters

Voltage - Supply, Single/Dual (±): 2.5V ~ 16V, ±1.25V ~ 8V

Voltage - Input Offset (Max): 3.6mV @ 15V

Current - Input Bias (Max): 250pA @ 15V

Current - Output (Typ): 10mA

Current - Quiescent (Max): 950nA

Propagation Delay (Max): 300µs

Quality and Safety Features

Operational stability over 0°C ~ 70°C temperature range

High-quality control standards as per Texas Instruments

Compatibility

SOT-23-5 package universally used for surface mount applications

Compatible with wide power supply range

Application Areas

Voltage level detection

Signal processing

Battery management systems

Window comparators

Relay drivers

Product Lifecycle

Last Time Buy status indicating approaching discontinuation

Potential availability of future replacements or upgrades should be verified with Texas Instruments

Several Key Reasons to Choose This Product

Highly reliable performance for precision applications

Versatile in handling low to moderate power supply voltages

Energy efficient enabling it for portable and battery-operated devices

Exemplary noise performance making it suitable for noisy environments

The small form factor of the SC-74A, SOT-753 package for compact circuit designs

Comprehensive design and customer support from Texas Instruments
