Manufacturer Part Number
TLV1701AIDBVT
Manufacturer
Texas Instruments
Introduction
General-purpose linear comparator for electronic signal processing
Product Features and Performance
Single comparator element
Open-collector output
Input voltage range: 2.2V to 36V, or ±1.1V to ±18V
Maximum input offset voltage: 3.5mV
Maximum input bias current: 0.015µA
Typical output current: 20mA
Maximum quiescent current: 75µA
Propagation delay maximum: 560ns
Operating temperature range from -40°C to 125°C
Product Advantages
Wide voltage supply range for flexibility in different applications
Ultra-low input bias current for higher accuracy
Energy-efficient with low quiescent current
Fast response with sub-microsecond propagation delay
Robust operating temperature range suitable for industrial applications
Key Technical Parameters
Voltage supply range: 2.2V ~ 36V, ±1.1V ~ 18V
Input offset voltage: 3.5mV
Input bias current: 0.015µA
Output current: 20mA
Quiescent current: 75µA
Propagation delay: 560ns
Quality and Safety Features
Extended temperature range for reliable performance in extreme conditions
Surface mount SC-74A, SOT-753 package for secure mounting
Compatibility
Supports single or dual supply operation
Compatible with various digital logic families with open-collector output
Application Areas
Industrial control systems
Automotive electronics
Signal processing
Data acquisition systems
Power management
Product Lifecycle
Product status is active
No immediate discontinuation, replacements, or upgrades indicated
Several Key Reasons to Choose This Product
Wide supply voltage range enabling use in various electronic systems
High precision with low input offset and low bias current contributing to accurate signal processing
Low power consumption ideal for energy-sensitive applications
Suitable for a variety of applications due to general-purpose design
Industry-standard package and surface mount type facilitating integration into PCB designs
Reputable manufacturer providing reliable and consistent product quality
Available in tape & reel packaging for efficient assembly and manufacturing processes
Technical support and resources available from Texas Instruments
