SN75LVPE4410RNQR - Texas Instruments

Manufacturer Part Number

SN75LVPE4410RNQR

Manufacturer

Texas Instruments

Introduction

The SN75LVPE4410RNQR is part of Texas Instruments' high-speed signal conditioning product family, designed mainly for PCI Express applications.

Product Features and Performance

Supports maximum data rate of 16Gbps

Four bidirectional channels

Minimal delay time of 70ps

Input equalization for signal integrity improvement

Output de-emphasis to reduce signal distortion

Low input capacitance of 1.5 pF

Product Advantages

Enhanced signal quality for high-speed interfaces

Suitable for multi-gigabit data transmission

Key Technical Parameters

Data Rate (Max): 16Gbps

Number of Channels: 4

Delay Time: 70ps

Voltage Supply: 3V ~ 3.6V

Current Supply: 90mA

Operating Temperature Range: 0°C ~ 70°C

Quality and Safety Features

Built to Texas Instruments' rigorous quality standards

Reliable performance across specified operating conditions

Compatibility

Designed for use with PCI Express interfaces

Application Areas

High-speed data communication

Servers, networking equipment, and storage systems

Data centers and computing infrastructure

Product Lifecycle

Active status; not listed as nearing discontinuation

Long-term availability expected

Several Key Reasons to Choose This Product

Reduces bit error rates in high-speed data transmission

Four high-speed channels increase data throughput

Texas Instruments' reputation for reliability and technical support

Easy to integrate into existing designs due to surface mount packaging

Suitable for multiple PCI Express generations, ensuring future utility
