SN74LVC1G125DBVR - Texas Instruments

Manufacturer Part Number

SN74LVC1G125DBVR

Manufacturer

Texas Instruments

Introduction

Single Buffer/Driver with 3-State Output

Product Features and Performance

Non-Inverting Logic Buffer

Single Element with One Bit per Element

3-State Output for Bus Interfacing

Operates from 1.65V to 5.5V

Supports 5V Tolerant I/O

Low Static Power Consumption

Low Dynamic Power Consumption

ESD Protection Exceeds JESD 22

Product Advantages

High Drive Current Output (32mA)

Wide Operating Temperature Range -40°C to 125°C

Suits Various Logic Signal Levels due to Broad Voltage Range

Key Technical Parameters

Logic Family: 74LVC

Supply Voltage Range: 1.65V ~ 5.5V

Output Current: ±32mA

Operating Temperature: -40°C ~ 125°C

Package Type: SC-74A, SOT-753

Quality and Safety Features

Built-In ESD Protection

Latch-Up Performance Exceeds 100mA Per JESDEC Standard

Compatibility

Compatible with Down-Voltage Systems

5V Tolerant Inputs

SC-74A, SOT-753 Package Compatible with SMT Processes

Application Areas

Signal Routing

Logic Level Shifting

I/O Expansion

Data Bus Control and Isolation

Product Lifecycle

Active Product Status

Non-Discontinued with Ongoing Support

Availability of Replacements or Upgrades

Several Key Reasons to Choose This Product

Supports Mixed-Voltage Operation for System Flexibility

Low Power Dissipation for Energy-Efficient Designs

High Output Drive for Driving Heavy Loads

Compact SOT-23-5 Package for Space-Constrained Applications

Industry-Standard Logic Device, Ensuring Ease of Design and Replacement

Direct Availability and Support From Texas Instruments
