SN74LVC126APWR - Texas Instruments

Manufacturer Part Number

SN74LVC126APWR

Manufacturer

Texas Instruments

Introduction

The SN74LVC126APWR is a part of the 74LVC series, serving as a quad buffer with non-inverting configuration, designed for usage in applications requiring a 3-state output to drive bus lines.

Product Features and Performance

Features four non-inverting buffer elements

Each element has a 3-state output

Operates from a supply voltage of 1.65V to 3.6V

Can source or sink currents up to 24mA

Designed for minimal propagation delay and high noise immunity

Operates over a broad temperature range from -40°C to 125°C

Product Advantages

Suitable for 5V tolerant applications

Low power consumption optimal for battery-operated devices

High output drive capability

Compatibility with high-speed bus operations

Key Technical Parameters

Logic Type: Buffer, Non-Inverting

Number of Elements: 4

Number of Bits per Element: 1

Output Type: 3-State

Current Output High, Low: 24mA, 24mA

Voltage Supply: 1.65V ~ 3.6V

Operating Temperature: -40°C ~ 125°C (TA)

Quality and Safety Features

Built to adhere to stringent quality control measures

Over-temperature and over-current protection built in

Reliability under varied environmental conditions

Compatibility

Compatible with other logic families in the 74LVC series

Can interface with CMOS, NMOS, and TTL logic circuits

Application Areas

Communication systems

Data processing

Industrial automation

Consumer electronics

Product Lifecycle

Currently listed as Active

Long-term availability supported, without near-term discontinuation risks

Potential future upgrades or replacements available as technology progresses

Several Key Reasons to Choose This Product

High reliability for applications operating at extreme temperatures

Ensures signal integrity with its high output capability

Provides flexibility in system design through its 3-state outputs

Low voltage operation suitable for modern low-power devices

Direct compatibility with various microcontrollers and other digital systems
