SN74LS164DR - Texas Instruments

Manufacturer Part Number

SN74LS164DR

Manufacturer

Texas Instruments

Introduction

The SN74LS164DR is a serial-input, parallel-output logic shift register from the 74LS series, designed for digital signal processing tasks.

Product Features and Performance

Integrates seamlessly into various electronic circuits

Efficient serial to parallel data conversion

8-bit parallel output for broad applicability

Operates with a supply voltage range of 4.75V to 5.25V, suitable for TTL logic levels

Push-Pull output type for stronger drive capability

Optimized for a 0°C to 70°C operating temperature range

Product Advantages

Reliability and longevity associated with the Texas Instruments brand

Enhanced data handling and smooth conversion performance

Low power consumption enhances system efficiency

Compact SOIC package facilitates dense circuit designs

Key Technical Parameters

Logic Type: Shift Register

Number of Elements: 1

Number of Bits per Element: 8

Voltage Supply: 4.75V ~ 5.25V

Operating Temperature: 0°C ~ 70°C

Package / Case: 14-SOIC

Quality and Safety Features

Manufactured under strict quality standards

Compliant with major industry safety norms and directives

Compatibility

Compatible with a broad range of microcontrollers and digital signal processors

Application Areas

Digital signal processing

Data storage devices

Communication systems

Consumer electronics

Automotive electronics

Product Lifecycle

Currently in active production

No announced discontinuation, ensuring long-term availability

Upgrades and replacements available for future-proof designs

Several Key Reasons to Choose This Product

Proven performance backed by Texas Instruments’ reputation

Ideal for complex digital processing needs in a compact form factor

Easy integration with existing digital systems

Cost-effective solution for serial to parallel data conversion tasks

Comprehensive support and documentation available from Texas Instruments
