Manufacturer Part Number
SN74ALS86N
Manufacturer
Texas Instruments
Introduction
The SN74ALS86N is a quad 2-input exclusive-OR (XOR) gate integrated circuit (IC) from Texas Instruments.
It belongs to the 74ALS (Advanced Low-power Schottky) series, which offers high-speed performance and low power consumption.
Product Features and Performance
4 independent XOR gates in a single package
High-speed operation with a maximum propagation delay of 17 ns at 5 V and 50 pF load
Low power consumption with an output current of up to 400 μA in the high state and 8 mA in the low state
Operates on a 4.5 V to 5.5 V supply voltage
Supports operating temperatures from 0°C to 70°C
Product Advantages
Compact 14-pin dual inline package (DIP) for easy through-hole mounting
Excellent performance-to-power ratio for efficient digital logic design
Robust design with good noise immunity and ESD protection
Key Technical Parameters
Number of Inputs: 2 per gate
Number of Circuits: 4 independent XOR gates
Input Logic Level High: 2 V
Input Logic Level Low: 0.8 V
Current Output High/Low: 400 μA / 8 mA
Logic Type: Exclusive OR (XOR)
Quality and Safety Features
RoHS3 compliant for environmental responsibility
Rigorous quality control and testing by Texas Instruments
Compatibility
The SN74ALS86N is a direct replacement for legacy 74LS86 XOR gate ICs, offering improved performance and compatibility.
Application Areas
Digital logic design
Boolean algebra implementation
Arithmetic circuits
Data processing and communication systems
Product Lifecycle
The SN74ALS86N is a mature and widely used product, with no indication of discontinuation.
Replacement or upgraded options are available from Texas Instruments and other manufacturers if required.
Key Reasons to Choose This Product
High-speed, low-power performance for efficient digital logic design
Robust and reliable design with good noise immunity and ESD protection
Easy integration with existing systems due to compatibility with legacy 74LS86 devices
Trusted Texas Instruments quality and support
