SN74ALS574BNSR - Texas Instruments

Manufacturer Part Number

SN74ALS574BNSR

Manufacturer

Texas Instruments

Introduction

Logic flip-flop integrated circuit for digital data storage and transfer

Product Features and Performance

D-Type flip-flop with tri-state non-inverted output

Eight-bit data storage per element

Supports clock frequencies up to 35 MHz

Fast propagation delay of 14ns at 5V and 50pF load

Positive edge-triggered

Supports 4.5V to 5.5V power supply

Surface mount 20-SOIC package

Product Advantages

High-speed performance suitable for fast digital circuits

Low power consumption with 18 mA quiescent current

Robust operating temperature range from 0°C to 70°C

Tri-state output for bus interfacing

Key Technical Parameters

Clock Frequency: 35 MHz

Max Propagation Delay: 14ns at 5V, 50pF

Current - Output High/Low: 2.6mA/24mA

Voltage - Supply Range: 4.5V to 5.5V

Operating Temperature: 0°C to 70°C

Mounting Type: Surface Mount

Quality and Safety Features

Manufactured by Texas Instruments, a leader in semiconductor solutions

Compliant with standard safety and environmental regulations

Durable construction for consistent performance

Compatibility

Compatible with 5V digital systems

Suitable for use with multiple semiconductor components and microprocessors

Application Areas

Digital communication systems

Data storage and retrieval systems

Computer motherboards and hardware

Industrial control systems

Product Lifecycle

Currently active product

Not indicated as nearing discontinuation

Manufacturer support for replacements or upgrades should be available

Several Key Reasons to Choose This Product

High clock frequency capability suitable for demanding digital applications

Low propagation delay ensures rapid data processing

Manufactured by a reputable company with a track record of quality and reliability

Tri-state output increases circuit design flexibility

Versatile power supply compatibility simplifies integration

Available in Surface Mount Technology (SMT) for modern PCB design standards
