SN74ALS273NSR - Texas Instruments

Manufacturer Part Number

SN74ALS273NSR

Manufacturer

Texas Instruments

Introduction

The SN74ALS273NSR from Texas Instruments is a master reset D-type logic flip flop, a fundamental component used in digital circuits to store binary data.

Product Features and Performance

Single D-type flip-flop with master reset function

Non-Inverted output

Contains one element with 8-bits per element

Operates at a clock frequency of up to 35 MHz

Maximum propagation delay of 15ns at 5V, 50pF

Positive edge-triggered

Offers output current of 2.6mA (high) and 24mA (low)

Supply voltage range between 4.5V and 5.5V

Quiescent current of 20 mA

Designed for surface mount applications with a 20-SOIC package

Product Advantages

High clock speed support enhances performance in timing-sensitive applications

Low propagation delay ensures quick response to input signals

Positive edge trigger allows for precise control of data timing

Suitable for a wide range of supply voltages, enhancing versatility

Low quiescent current helps in reducing power consumption

Key Technical Parameters

Clock Frequency: 35 MHz

Propagation Delay: 15ns @ 5V, 50pF

Output Current: 2.6mA (High), 24mA (Low)

Supply Voltage: 4.5V ~ 5.5V

Quiescent Current: 20 mA

Operating Temperature Range: 0°C ~ 70°C

Quality and Safety Features

Manufactured by Texas Instruments, a leader in semiconductor design and production, ensuring high reliability and performance standards.

Compatibility

Compatible with other 74ALS series logic components and a broad range of digital circuits requiring D-type flip-flop functionality.

Application Areas

Widely used in data storage, shift registers, counters, and control circuits in both commercial and industrial electronics.

Product Lifecycle

Currently active, implying continuous production with no immediate threat of discontinuation. Future replacements or upgrades would likely maintain or improve upon the current operational parameters.

Several Key Reasons to Choose This Product

High-speed operation and low propagation delay are critical for real-time applications.

Versatility in power supply compatibility ensures ease of integration into existing designs.

Manufactured by Texas Instruments, ensuring reliability and state-of-the-art semiconductor technology.

Broad application range from industrial control systems to consumer electronics, making it a versatile choice for various projects.

Active product status with Texas Instruments’ reputation for product longevity offers long-term usability and support.
