HomeProductsIntegrated Circuits (ICs)PMIC - Voltage ReferenceREF2030QDDCRQ1
REF2030QDDCRQ1 Image
REF2030QDDCRQ1 Image - 1
Image may be representation.
See specifications for product details.
Share
 Favorite

REF2030QDDCRQ1 - Texas Instruments

Manufacturer Part Number
REF2030QDDCRQ1
Manufacturer
Texas Instruments
Allelco Part Number
32D-REF2030QDDCRQ1
ECAD Model
Parts Description
AUTOMOTIVE LOW-DRIFT, LOW-POWER,
Detailed Description
Package
SOT-23-5 Thin, TSOT-23-5
Data sheet
REF20xx-Q1.pdf
Compare
In stock: 14674

Required fields are indicated by an asterisk (*)
Please send RFQ, we will respond immediately.

Quantity

Specifications

REF2030QDDCRQ1 Tech Specifications
Texas Instruments - REF2030QDDCRQ1 technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - REF2030QDDCRQ1

Product Attribute Attribute Value
Manufacturer Texas Instruments
Voltage - Output (Min/Fixed) 1.5V, 3V
Voltage - Input 2.28V ~ 5.5V
Tolerance ±0.05%
Temperature Coefficient 8ppm/°C
Supplier Device Package SOT-23-THIN
Series Automotive, AEC-Q100
Reference Type Series
Package / Case SOT-23-5 Thin, TSOT-23-5
Product Attribute Attribute Value
Package Tape & Reel (TR)
Output Type Fixed
Operating Temperature -40°C ~ 125°C
Noise - 10Hz to 10kHz -
Noise - 0.1Hz to 10Hz 12ppmp-p
Mounting Type Surface Mount
Current - Supply 460µA
Current - Output 20 mA
Base Product Number REF2030

Parts Introduction

Manufacturer Part Number

REF2030QDDCRQ1

Manufacturer

Texas Instruments

Introduction

Precision Low-Drop Voltage Reference

Product Features and Performance

Series Voltage Reference Type

Fixed Output Voltage Options: 1.5V and 3V

High Current Output Capability: 20 mA

Low Temperature Coefficient: 8ppm/°C

Very Low Noise Performance: 12ppmp-p (0.1Hz to 10Hz)

Stable with Capacitive Loads

Product Advantages

Exceptional Temperature Stability

High Output Current

Low Noise for Sensitive Applications

Low Dropout Voltage

Key Technical Parameters

Output Voltage Range: 1.5V, 3V

Tolerance: ±0.05%

Input Voltage Range: 2.28V to 5.5V

Supply Current: 460µA

Operating Temperature Range: -40°C to 125°C

Automotive Grade Quality

Quality and Safety Features

AEC-Q100 Qualified for Automotive Applications

Robust Performance in Wide Temperature Ranges

Compatibility

Compatible with Surface Mount Technology

Mounting Type: SOT-23-5 Thin, TSOT-23-5

Application Areas

Automotive Systems

Precision Instrumentation

Data Acquisition Systems

Portable and Battery-Powered Devices

Product Lifecycle

Status: Active

No Indication of Nearing Discontinuation

Replacements or Upgrades are Typically Available

Several Key Reasons to Choose This Product

Accurate Fixed Voltage for Reliable References

Suitable for Automotive and Stringent Applications

Low Operational Current for Power Saving

Built For Direct Surface Mounting on Circuit Boards

Texas Instruments' Reputation for Reliable and Durable Components

Parts with Similar Specifications

The three parts on the right have similar specifications to Texas Instruments REF2030QDDCRQ1

Product Attribute REF2030QDDCRQ1 REF2041AIDDCR REF2025AIDDCT REF2030AIDDCT
Part Number REF2030QDDCRQ1 REF2041AIDDCR REF2025AIDDCT REF2030AIDDCT
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Package Tape & Reel (TR) Tape & Reel (TR) Tape & Reel (TR) Tape & Reel (TR)
Voltage - Output (Min/Fixed) 1.5V, 3V 2.048V, 4.096V 1.24V, 2.5V 1.5V, 3V
Package / Case SOT-23-5 Thin, TSOT-23-5 SOT-23-5 Thin, TSOT-23-5 SOT-23-5 Thin, TSOT-23-5 SOT-23-5 Thin, TSOT-23-5
Operating Temperature -40°C ~ 125°C -40°C ~ 125°C (TA) -40°C ~ 125°C (TA) -40°C ~ 125°C (TA)
Supplier Device Package SOT-23-THIN SOT-23-THIN SOT-23-THIN SOT-23-THIN
Output Type Fixed Fixed Fixed Fixed
Noise - 10Hz to 10kHz - - - -
Noise - 0.1Hz to 10Hz 12ppmp-p 12ppmp-p 12ppmp-p 12ppmp-p
Current - Output 20 mA 20 mA 20 mA 20 mA
Current - Supply 460µA 460µA 460µA 460µA
Voltage - Input 2.28V ~ 5.5V 4.116V ~ 5.5V 2.52V ~ 5.5V 3.02V ~ 5.5V
Base Product Number REF2030 REF2041 REF2025 REF2030
Series Automotive, AEC-Q100 - - -
Tolerance ±0.05% ±0.05% ±0.05% ±0.05%
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount
Temperature Coefficient 8ppm/°C 8ppm/°C 8ppm/°C 8ppm/°C
Reference Type Series Series Series Series

REF2030QDDCRQ1 Datasheet PDF

Download REF2030QDDCRQ1 pdf datasheets and Texas Instruments documentation for REF2030QDDCRQ1 - Texas Instruments.

Datasheets
REF20xx-Q1.pdf
