PCA9548ADWR - Texas Instruments

Manufacturer Part Number

PCA9548ADWR

Manufacturer

Texas Instruments

Introduction

The PCA9548ADWR is a 1-of-8 I2C-bus switch/multiplexer that allows a single I2C/SMBus master to communicate with multiple I2C/SMBus slaves. It is designed for use in systems where more than one I2C/SMBus device needs to be accessed by a single master.

Product Features and Performance

Provides eight bidirectional channels

Requires only one address for all eight channels

Low power consumption

On-chip logic control

Individual channel enable/disable

Propagation delay of 35 ns (typical)

Latch-up performance exceeds 100 mA per JESD 78 Class II

ESD protection exceeds 4 kV human body model (HBM) and 1 kV charged device model (CDM) per JESD 22

Product Advantages

Enables efficient I2C/SMBus communication in systems with multiple slaves

Saves board space and reduces component count

Low power consumption for power-sensitive applications

Robust design with high ESD and latch-up protection

Key Technical Parameters

Operating voltage: 2.3V to 5.5V

I2C/SMBus data rate: Up to 400 kHz

Propagation delay: 35 ns (typical)

ESD protection: 4 kV HBM, 1 kV CDM

Quality and Safety Features

RoHS3 compliant

Tape and reel packaging for efficient manufacturing

Compatibility

Compatible with I2C/SMBus protocols

Works with a wide range of I2C/SMBus devices

Application Areas

Embedded systems

Industrial control

Automotive electronics

Consumer electronics

Product Lifecycle

The PCA9548ADWR is an active product and not nearing discontinuation.

Replacement or upgrade options are available from Texas Instruments.
