LP38691SD-ADJ - Texas Instruments

Manufacturer Part Number
LP38691SD-ADJ
Manufacturer
Texas Instruments
Allelco Part Number
32D-LP38691SD-ADJ
ECAD Model
Parts Description
IC REG LIN POS ADJ 500MA 6WSON
Detailed Description
Package
6-WDFN Exposed Pad
Data sheet
LP38691/93-ADJ.pdf
RoHs Status
ROHS3 Compliant
Compare
In stock: 35896

Required fields are indicated by an asterisk (*)
Please send RFQ, we will respond immediately.

Quantity

Specifications

LP38691SD-ADJ Tech Specifications
Texas Instruments - LP38691SD-ADJ technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - LP38691SD-ADJ

Product Attribute Attribute Value
Manufacturer Texas Instruments
Voltage Dropout (Max) -
Voltage - Output (Min/Fixed) 1.25V
Voltage - Output (Max) 9V
Voltage - Input (Max) 10V
Supplier Device Package 6-WSON (3x3)
Series Automotive, AEC-Q100
Protection Features Over Temperature
Package / Case 6-WDFN Exposed Pad
Package Tape & Reel (TR)
PSRR 55dB (120Hz)
Product Attribute Attribute Value
Output Type Adjustable
Output Configuration Positive
Operating Temperature -40°C ~ 125°C
Number of Regulators 1
Mounting Type Surface Mount
Current - Supply (Max) 100 µA
Current - Quiescent (Iq) 55 µA
Current - Output 500mA
Control Features -
Base Product Number LP38691

Parts Introduction

Manufacturer Part Number

LP38691SD-ADJ

Manufacturer

Texas Instruments

Introduction

Integrated circuit (IC) voltage regulator

Adjustable output voltage

Product Features and Performance

Output voltage range: 1.25V to 9V

Output current: 500mA

Quiescent current: 55μA

Supply current: 100μA max

Excellent line and load regulation

High power supply rejection ratio (PSRR) of 55dB at 120Hz

Low dropout voltage

Product Advantages

Adjustable output voltage for versatile applications

High efficiency and low power consumption

Compact 6-pin WSON (3x3) package

Supports wide input voltage range

Key Technical Parameters

Operating temperature range: -40°C to 125°C

Automotive-grade, AEC-Q100 qualified

ROHS3 compliant

Quality and Safety Features

Overtemperature protection

Robust design for automotive and industrial applications

Compatibility

Suitable for a variety of electronic devices and systems

Application Areas

Automotive electronics

Industrial equipment

Consumer electronics

Product Lifecycle

Current product, no discontinuation plans

Replacements and upgrades may be available in the future

Key Reasons to Choose This Product

Adjustable output voltage for versatile applications

High efficiency and low power consumption

Robust automotive-grade design

Compact and space-saving package

Comprehensive protection features for reliable operation

Parts with Similar Specifications

The three parts on the right have similar specifications to Texas Instruments LP38691SD-ADJ

Product Attribute LP38691SD-ADJ LP38691SDX-5.0 LP38691SDX-3.3 LP38691SD-5.0
Part Number LP38691SD-ADJ LP38691SDX-5.0 LP38691SDX-3.3 LP38691SD-5.0
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount
Supplier Device Package 6-WSON (3x3) 6-WSON (3x3) 6-WSON (3x3) 6-WSON (3x3)
Current - Quiescent (Iq) 55 µA 55 µA 55 µA 55 µA
Output Configuration Positive Positive Positive Positive
Voltage - Input (Max) 10V 10V 10V 10V
Current - Supply (Max) 100 µA 100 µA 100 µA 100 µA
PSRR 55dB (120Hz) 55dB (120Hz) 55dB (120Hz) 55dB (120Hz)
Control Features - - - -
Voltage - Output (Min/Fixed) 1.25V 5V 3.3V 5V
Current - Output 500mA 500mA 500mA 500mA
Protection Features Over Temperature Over Temperature Over Temperature Over Temperature
Voltage Dropout (Max) - 0.45V @ 500mA 0.55V @ 500mA 0.45V @ 500mA
Series Automotive, AEC-Q100 Automotive, AEC-Q100 Automotive, AEC-Q100 Automotive, AEC-Q100
Output Type Adjustable Fixed Fixed Fixed
Package / Case 6-WDFN Exposed Pad 6-WDFN Exposed Pad 6-WDFN Exposed Pad 6-WDFN Exposed Pad
Voltage - Output (Max) 9V - - -
Package Tape & Reel (TR) Tape & Reel (TR) Tape & Reel (TR) Tape & Reel (TR)
Operating Temperature -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C
Base Product Number LP38691 LP38691 LP38691 LP38691
Number of Regulators 1 1 1 1
