LMC7101AIM5 - Texas Instruments

Manufacturer Part Number

LMC7101AIM5

Manufacturer

Texas Instruments

Introduction

The LMC7101AIM5 is a high-performance, low-noise, general-purpose operational amplifier (op-amp) designed for a wide range of industrial and consumer applications.

Product Features and Performance

Rail-to-rail input and output

Low input offset voltage of 110 μV

Low input bias current of 1 pA

Gain bandwidth product of 1.1 MHz

Slew rate of 1.1 V/μs

Wide supply voltage range of 2.7 V to 15.5 V

Low quiescent current of 800 μA

Output current capability of 50 mA

Product Advantages

Excellent performance for precision instrumentation and low-power applications

Suitable for both single-supply and dual-supply operation

Small SOT-23-5 package for compact designs

Robust and reliable operation over a wide temperature range of -40°C to 85°C

Key Technical Parameters

Voltage Supply Span (Min): 2.7 V

Voltage Supply Span (Max): 15.5 V

Current Supply: 800 μA

Gain Bandwidth Product: 1.1 MHz

Slew Rate: 1.1 V/μs

Voltage Input Offset: 110 μV

Current Input Bias: 1 pA

Current Output / Channel: 50 mA

Quality and Safety Features

ROHS3 compliant

Suitable for industrial and consumer applications

Compatibility

Surface mount package (SOT-23-5)

Compatible with a wide range of electronic systems and circuits

Application Areas

Precision instrumentation

Low-power analog circuits

Industrial and consumer electronics

Product Lifecycle

Current product, not nearing discontinuation

Replacement and upgrade options available from Texas Instruments

Key Reasons to Choose This Product

Excellent performance characteristics, including low noise, high bandwidth, and low power consumption

Versatile operation in both single-supply and dual-supply configurations

Compact and reliable surface mount package

Suitable for a wide range of industrial and consumer applications

Backed by the quality and support of Texas Instruments
