Manufacturer Part Number
ISO7740FDBQ
Manufacturer
Texas Instruments
Introduction
The ISO7740FDBQ is a high-speed, quad-channel digital isolator from Texas Instruments. It provides reliable data transmission between electrical systems while maintaining galvanic isolation.
Product Features and Performance
4 channels of digital isolation
High-speed data transfer up to 100Mbps
Extremely fast rise/fall times of 2.4ns
Low propagation delay of 16ns maximum
High common-mode transient immunity of 85kV/s
Wide operating temperature range of -55°C to 125°C
Operates on a wide supply voltage of 2.25V to 5.5V
Product Advantages
Excellent isolation performance for safety and reliability
High-speed data transfer for real-time applications
Low power consumption
Small 16-SSOP package for space-constrained designs
Key Technical Parameters
5000Vrms isolation voltage
9ns maximum pulse width distortion
Unidirectional channel configuration
Quality and Safety Features
RoHS3 compliant
Surface mount package for reliable assembly
Compatibility
Compatible with a variety of microcontrollers and digital systems
Application Areas
Industrial automation
Motor control
Power supplies
Medical equipment
Instrumentation
Product Lifecycle
No indication of discontinuation
Replacements and upgrades may be available from Texas Instruments
Key Reasons to Choose This Product
Reliable galvanic isolation for safety and signal integrity
High-speed data transfer for real-time applications
Low power consumption and small package size
Wide operating temperature range and RoHS compliance
Proven performance and quality from Texas Instruments
